Advance Marine Gearbox Hc138 for Shangchai 6135ca Diesel Engine

Fuan Tongbo Electrical Machinery Co., Ltd.

Application：Marine
Function：Clutch
Layout：Cycloidal
Hardness：Hardened Tooth Surface
Installation：Vertical Type
Step：Single-Step

Base Info

Model NO.：HC138
Type：Planetary Gear Box
Certificate：CCS
Warranty：1 Year
Delivery Time：30 Days
Colour：Blue, Grey,Orange
Transport Package：1PCS Into One Plywood Case
Specification：HC138
Trademark：Advance
Origin：Hangzhou
HS Code：8483409000
Production Capacity：200PCS Per Month

Description

Input speed1000-2500r/minReduction ratio2.0,2.52,3.00,3.57,4.05,4.45Trans. capacity0.110kw/r/minControl wayPush-and-pull flexible shaft, electrically, pneumaticallyRated thrust30KNCenter distance225mmL×W×H520×792×760mmNet weight360kgFlywheel6135Ca,SAE14,11.5Bell housing6135Ca,SAE1,2,3

Application

Marine Gearbox HC138 is suitable for medium and small fishing, transport, tug, traffic and passenger boats.
