Advance Marine transmission Gearbox 16A for 1000-2000rpm Marine Engine

Fuan Tongbo Electrical Machinery Co., Ltd.

Application：Marine
Function：Clutch
Layout：Cycloidal
Hardness：Hardened Tooth Surface
Installation：Vertical Type
Step：Single-Step

Base Info

Model NO.：16A
Type：Planetary Gear Box
Certificate：CCS
Warranty：1 Year
Delivery Time：30 Days
Colour：Blue, Grey
Transport Package：1PCS Into One Plywood Case
Specification：16A
Trademark：Advance
Origin：Hangzhou
HS Code：8483409000
Production Capacity：200PCS Per Month

Description

Input speed1000-2000r/minReduction ratio2.07,2.48,2.95,3.35,3.83Trans. capacity0.012kw/r/minControl wayManuallyRated thrust3.5KNCenter distance135mmL×W×H422×325×563mmNet weight84kgFlywheel2105C 395,SAE11.5,10Bell housing2105C 395,SAE3,4
Application

Marine Gearbox 16A is suitable for small fishing, transport, and rescue boats.
