R Series Helical Gear Speed Reducer Gearmotor with Hard Surface

Shanghai SGR Heavy Industry Machinery Co., Ltd.
  • Application：Motor, Electric Cars, Machinery, Marine, Agricultural Machinery
  • Function：Change Drive Torque, Change Drive Direction, Speed Changing, Speed Reduction, Speed Increase
  • Layout：Coaxial
  • Hardness：Hardened Tooth Surface
  • Installation：Horizontal Type
  • Step：Four-Step

Base Info

  • Type：Planetary Gear Box
  • Transport Package：Wooden Case
  • HS Code：8483409000
  • Production Capacity：400PCS,Month

Description

Housing material                                     HT200 high-strength cast iron from R37,47,57,67,77,87                                                                                     Housing material    HT250 High strength cast iron from R97 107,137,147,
157,167,187Housing hardnessHBS90-240Gear material:20CrMnTiSurface hardnesss  of gear    HRC58°-62°Gear core hardnessHRC33°-40°Input/Output shaft material          40CrInput/Output shaft hardnessHBS241°-286°Shaft at oil seal postion hardnessHRC48 ° -55 °Machining precision of gears  materialAccurate grinding 6-5 gradeHeat treatmenttempering, cementing, quenching etcEfficiencyup to 90%Noise(Max)60-68dBUnit modelFoot mounted,flange mountedInput methodflange input,inline input,shaft inputVibration≤20umBacklash≤20ArcminBearing brandsNSK,C&U etcOil seal brandsNAK,SKF etcLubricantVG220MotorIP55, F classMotor shaft40Cr, Tempering, cementing,quenching etc.


Applications

Foshan XG Transmission Gearbox reducer are widely used in :
Ceramic Industry
Glass Industry
Food Industry
Metallurgy Industry
Beer& Drink Industry
Printing and dyeing Industry
Textile Industry
Warehouse Logoistics Industry
Wood working Machinery
environmental protection equipment Industry
Leather Industry
Pharmacy Industry



R Series Helical Gear Speed Reducer Gearmotor with Hard Surface
R Series Helical Gear Speed Reducer Gearmotor with Hard Surface
R Series Helical Gear Speed Reducer Gearmotor with Hard Surface
R Series Helical Gear Speed Reducer Gearmotor with Hard Surface


FAQ:
1.Are you a factory or trader ?
We are a professional factory which has 20 years history specialized in gear transmission .
2.MOQ:
Our MOQ is 1pcs. However there is one handling cost $150 for the single order which less than $3000.00
3. Warranty
Our warranty is 12months
4. Payment term
100% T/T in advance and LC at sight .
5. Do you accept customization ?
YES.SGR have strong R&D team, we can provide customizable service according to requirements.
6. Packing
Generally we use standard export plywood case to arrange the shipment .
7. Delivery time
In normal ,time of delivery is 30days after receiving the prepayment .
8. What kinds of certification do you use ?
DNV-ISO9001:2008, SGS,CE etc, And new products patent.
9. What kinds of inspection you do before shipment ?
We do temperature test, noise, and oil leak inspection and commissioning before shipment.
10.How do you solve if the production have problem ?
Mostly, we don't need customer send the goods back to us. Because the cost is very high, if there meets a problem,we firstly ask for the pictures for damaged parts. And base on the pictures, we can have a basic idea for the defect reason. Our guarantee is 12 months, if during the guarantee, we can supply repair .
