Dlz2-120 24V Electromagnetic Clutch Power Brake for Lathe

Changzhou Suma Precision Machinery Co., Ltd.
  • Standard or Nonstandard：Standard
  • Application：Textile Machinery, Garment Machinery, Conveyer Equipment, Packaging Machinery, Mining Equipment, Agricultural Machinery
  • Surface Treatment：Other
  • Material：Steel
  • Product Name：Electromagnetic Clutch
  • Type：Electromagnetic Clutch

Base Info

  • Model NO.：DLZ2-120
  • OEM：Accept
  • Market：Global
  • Transport Package：Single Box or as Your Requirements
  • Specification：P0
  • Trademark：SUMA
  • Origin：Changzhou, Jiangsu, China
  • HS Code：84836000
  • Production Capacity：1000PCS,Month

Description

SIZErated dymanic torqueN.mStatic Torquerated voltage (DC V)coil consumption power(20°)Wallowed max revolvtion(r/min)ClutchBrakeClutchBrakeClutchBrakeDLZ2-1201200400132044024125951500DLZ2-180180080019808802001201200SIZERadial Demensions(mm)Axial Demensions(mm)D1D2D3D4JKLL1L2L3L4L5BδDLZ2-1204202051762054-M126-M10152.5777038252031.30.8DLZ2-1805002051802208-M128-M20183.8887061253553.80.8



Installation:

1. Doesn't need to adjust before mounted.

2.The coaxial degree of input and output axles are allowed not to exceed 0,1mm when mounted.

3.The bottom seat should be fixed hardenly.



Dlz2-120 24V Electromagnetic Clutch Power Brake for Lathe
Dlz2-120 24V Electromagnetic Clutch Power Brake for LatheDlz2-120 24V Electromagnetic Clutch Power Brake for Lathe
