Dly9-1500A

Changzhou Suma Precision Machinery Co., Ltd.
  • Standard or Nonstandard：Standard
  • Application：Textile Machinery, Garment Machinery, Conveyer Equipment, Packaging Machinery, Mining Equipment, Agricultural Machinery
  • Surface Treatment：Other
  • Material：Steel
  • Product Name：Electromagnetic Clutch
  • Type：Electromagnetic Clutch

Base Info

  • Model NO.：DLY9-1500A
  • OEM：Accept
  • Market：Global
  • Transport Package：Single Box or as Your Requirements
  • Specification：P0
  • Trademark：SUMA
  • Origin：Changzhou, Jiangsu, China
  • HS Code：84836000
  • Production Capacity：1000PCS,Month

Description

SIZERadial Demensions(mm)Axial Demensions(mm)D1D2D3D4D5D6D7ΦheLL1L2L3L4L5L6δDLY9-500A320270215130130200285110H7116.4282451051051014.58191DLY9-800A380315235150153225334118G7124.4288300120130122010301.3DLY9-1000A420350255140160230370110H7116.428310135135122010231.5DLY9-1500A460380265148180250400118G7124.428350140160122010401.8




Installation:

1.The clutch can be installed either in horizontal or in verial,If it mounted no the alex,the coaxlal degree between the driving and the driven shaft should not exceed 0.05mm,and must ensure the work clearence value σ.

2.The teeth of both ends should be cleaned before mounting the clutch. 3.The driving and the driven parts of the clutch must be fixed in axial direction,its axial moving doesn't permitted.
