Rolling Worn Gear Shafts Twisting Left or Twisting Right
Shenzhen Hefa Gear Machinery Co., Ltd.- Application：Motor, Electric Cars, Motorcycle, Machinery, Marine, Toy, Agricultural Machinery, Car
- Hardness：Hardened Tooth Surface
- Gear Position：External Gear
- Manufacturing Method：Rolling Gear
- Toothed Portion Shape：Curved Gear
- Material：Cast Steel
Base Info
- Model NO.：SW steel worm
- Type：Worm And Wormwheel
- Transport Package：with Plastic Bag,with Pearl-Cotton Package.
- Specification：Nonstandard
- Trademark：iHF
- Origin：Shenzhen China( Mainland)
- HS Code：84839000
- Production Capacity：500000 PCS, Year
Description
Materials AvailableStainless Steel, Carbon Steel etc BORE Finished bore, Pilot Bore, Special request Processing Method Molding, Shaving, Hobbing, Drilling, Tapping, Reaming, Manual Chamfering etc Pressure Angle 20 Degree Size Customer Drawings & ISO standard Package Wooden Case/Container and pallet, or made-to-order Certificate ISO9001:2008 Lead Time Within 30 days after get your payment
Other TypesPart NumberShape Number of Starts Shaft Bore Dia. PH7 Twisting Direction Advance Angle N O R S Type Module Straight Bore+Tap SW0.5-R1
SW0.5-R2 0.5 W2 1 5
R
(Right)
2°36' 11 12 18 3 W2 2 5 5°13' SW0.8-R1
SW0.8-R2 0.8 W2 1 6 3°17' 14 15.6 30 5 W2 2 6 6°34' SW1-R1
SW1-R2 1 W2 1 6 3°35' 16 18 32 5 W2 2 6 7°11' SW1.25-R1
SW1.25-R2 1.25 W2 1 8 3°25' 21 23.5 37 5 W2 2 8 6°50' SW1.5-R1 1.5 W1, W1T,W1K 1 8, 10 3°26' 25 28 40 5 SW1.5-R2 W1, W1T,W1K 2 8, 10 6°54' SW2-R1 2 W1, W1K 1 12, 14 R
(Right) 3°42' 31 35 46 7 SW2-R2 W1, W1K 2 12, 14 7°25' SW2-L1 W1, W1K 1 12, 14 L(Left) 3°42' 31 35 46 7 SW2-L2 W1, W1K 2 12, 14 7°25' SW2.5-R1 2.5 W1, W1K 1 15, 16 R
(Right) 3°52' 37 42 63 9 SW2.5-R2 2 15, 16 7°46' SW2.5-L1 W1, W1K 1 15, 16 L(Left) 3°52' 37 42 63 9 SW2.5-L2 2 15, 16 7°46' SW3-R2
3
W1, W1K 1 16,18,19,20 R
(Right) 3°55' 44 50 70 10 SW3-R2 2 16,18,19,20 7°50' SW3-L1 W1, W1K 1 16,18,19,20 L(Left) 3°55' 44 50 70 10 SW3-L2 2 16,18,19,20 7°50' SW4-R1
SW4-R2 4 W1 1 22 R
(Right) 3°42' 62 70 95 -- 2 7°25' SW4-L1 4 W1 1 22 L(Left) 3°42' 62 70 95 -- SW4-L2 2 7°25' SW5-R1 5 W3 1 25 R
(Right) 4°06' 70 80 125 -- SW5-R2 2 8°13' SW6-R1 6 W3 1 30 R
(Right) 4°18' 80 92 150 -- SW6-R2 2 8°38'
[ H ] Tooth Surface Hardness: 194HB or less[ A ] Accessories: Set Screw M4
Our company:
Hefa group was born in Shenzhen in 1998. It is a transmission component manufacturer committed to pursuing precision and speed. Hefa group adheres to the German precision planetary transmission design and manufacturing technology, and has more than 20 years of experience in the field of gear manufacturing. It is equipped with processing equipment such as LAISENHAUER gear grinding machine of Switzerland, CNC gear shaper of Mitsubishi Heavy Industry of Japan, CNC helical gear broaching machine of NACHI, hard tooth surface hobbing machine of Hamai and Qinchuan gear grinding machine. At the same time, it is also equipped with a series of precision gear testing equipment such as TTI gear tester of Japan, universal gear measuring instrument of Harbin quantity group and HEXAGON three coordinates, It has strong manufacturing ability and detection control ability, and can quickly provide professional solutions for customers in different fields.
Payment: T/T
Shipping : DHL, EMS, Air mail,TNT,UPS and FedEx.
If you are interested in our products, please tell us which materials, type, width, length u want.
