DIN Standard Staight Bevel Gear with Spline Mod4

Hangzhou Donghua Power Transmission Imp. & Exp. Co., Ltd.

Application：Motor, Motorcycle, Machinery, Agricultural Machinery
Manufacturing Method：Cut Gear
Toothed Portion Shape：Bevel Wheel
Type：Bevel Gear
Mod：0.5 1 1.5 2 2.5 3 4 4.5 5 6 8
Teeth Quantity：16 19 20 22 24 25 26 30 32 48 64

Base Info

Model NO.：M4T16
Transport Package：Export Package
Specification：DIN, ANSI, GB
Trademark：DONGHUA
Origin：China
HS Code：84839000
Production Capacity：5000PCS,Month

Description

Bevel GearGearSpline ISpline IIModuleMin1.51.5-Max5.04.0-Teeth NumberMin1630-Max3050-Pressure AngleMin17°20°-Max25°30°-Pitch AngleMin18°--Max56°--Spiral AngleMin20°--Max35°--O.DMin26--Max157--L(max) 200
DIN Standard Staight Bevel Gear with Spline Mod4
