• Model NO.：L-090
• Size：L-035 J-050 L-070-------L-150 L-190
• Max Bore：8 16 20 26 28 36 38 46 58
• Transport Package：Export Package
• Specification：ISO9001
• Trademark：DONGHUA
• Origin：China
• HS Code：8483600090
• Production Capacity：10000PCS,Month

Basic Info.

Model NO. L-090 Size L-035 J-050 L-070-------L-150 L-190 Max Bore 8 16 20 26 28 36 38 46 58 Transport Package Export Package Specification ISO9001 Trademark DONGHUA Origin China HS Code 8483600090 Production Capacity 10000PCS/Month

Product Description

DONGHUA Chain Group is the most professional manufacturer of power transmission in China, manufacturing roller chains, industry sprockets, motorcycle sprockets, casting sprockets, different type of couplings, pulleys, taper bushes, locking devices, gears, shafts, CNC precision parts and so on. We have passed ISO9001, ISO14001, TS16949 such quality and enviroment certification.

PRODUCT DESCRIPITION
*Excellet high torque rigidity and good vibration absorbability
*No gyration tolerance
*Great displacemet for angular, parallel or axial deviation by calw fecxibility
*Same feature revolving with direction or negative deredction.
*Fixed bye screw or deywqy
*Aluminum material, cast iron adn powder metallurgy
* Coupling type
L-035 L-050 L-070 L-075 L-090 L-095 L-099 L-100 L-110 L-150 L-190
We can supply various specification for couplings, HRC coupling, NM MHcoupling, flexible coupling, Jaw coupling, FCL coupling, ROTEX Coupling, bowex coupling etc
Pls contact to us on free, if you need catalogue or have any questions.

TYPE	Allowable Wrench Torque (N.m)	Max  (rpm)	Max Bore   (mm)	Out Dia  (mm)	Total Length (mm)	L1   (mm)	Weight   (kg)
L-035	0.15	6000	8	16.1	20.15	6.68	0.02
L-050	0.45	4500	16	27.6	42.55	15.60	0.14
L-070	0.9	3600	20	34.3	49.92	19.30	0.25
L-075	1.5	3600	26	44.6	52.88	20.60	0.45
L-090	2.4	3000	28	53.6	53.22	20.70	50.66
L-095	3	3000	28	53.6	62.36	25.20	0.78
L-099	6	3000	36	64.6	76.47	29.70	1.35
L-100	7.5	3000	36	64.6	86.47	34.70	1.53
L-110	15	2500	38	84.3	106.32	43.10	3.3
L-150	30	2500	46	95.3	112.95	44.60	4.48
L-190	45	2000	58	115	138.50	56.00	9.14
