Swp F Type Telescopic Long Cardan Shaft
Jingjiang Huading Machinery Manufacturing Co., Ltd.- Shaft Hole：19-32
- Torque：70-80N.M
Base Info
- Model NO.：SWP F type
- Bore Diameter：14mm
- Speed：6000r,M
- Structure：Rigid
- Material：Cast Iron
- Type：Rigid Coupling
- Delivery Time：Depend on Your Quantity
- Terms of Shipment：by Sea
- Color：Customer Required
- Transport Package：Wooden Case
- Specification：as your requirement
- Trademark：Huading
- Origin：Jingjiang, Jiangsu Province
- HS Code：8483600
- Production Capacity：10000pieces,Year
- Package size per unit product：274.00cm * 355.00cm * 300.00cm
- Gross weight per unit product：52.000kg
Description
Mass
kgLmin D1
js11 D2
H7 D3 E E1 B×h h1 L1 n-d Lmin Increase
100 Lmin Increase
100 SWP160F 160 16 8 ≤10 150 770 140 95 114 15 4 20×12 6 85 6-13 0.14 0.0059 51 2.1 SWP180F 180 20 10 ≤10 170 830 155 105 121 15 4 24×14 7 95 6-15 0.23 0.0072 64 2.3 SWP200F 200 31.5 16 ≤10 190 950 175 125 17 17 5 28×16 8 110 8-15 0.40 0.0114 88 3.4 SWP225F 225 40 20 ≤10 210 1070 196 135 152 20 5 32×18 9 130 8-17 0.66 0.0290 120 6.6 SWP250F 250 63 31.5 ≤10 220 1110 218 150 168 25 5 40×25 12.5 135 8-19 1.06 0.0407 158 7.3 SWP285F 285 90 45 ≤10 240 1270 245 170 194 27 7 40×30 15 150 8-21 2.24 0.0702 255 9.4 SWP315F 315 140 63 ≤10 270 1410 280 185 219 32 7 40×30 15 170 10-23 3.99 0.1144 344 12.0 SWP350F 350 180 90 ≤10 290 1540 310 210 245 35 8 50×32 16 185 10-23 6.90 0.1663 460 13.6 SWP390F 390 250 112 ≤10 315 1680 345 235 273 40 8 70×36 18 205 10-25 11.90 0.2695 600 18.0 SWP435F 435 355 160 ≤10 335 1880 385 255 299 42 10 80×40 20 235 16-28 22.41 0.3645 985 20.0 SWP480F 480 450 224 ≤10 350 2080 425 275 351 47 12 90×45 22.5 265 16-31 39.09 0.7028 1365 28.0 SWP550F 550 710 315 ≤10 360 2230 492 320 402 50 12 100×45 22.5 290 16-31 62.12 1.1842 1785 35.7 SWP600F 600 1000 500 ≤10 370 2800 544 380 450 55 15 90×55 27.5 360 22-34 100.48 1.7159 2403 40.5 SWP640F 640 1250 630 ≤10 380 2920 575 385 480 60 15 100×60 30 385 18-38 168.28 2.3080 3207 48.3
