• Model NO.：HB01-26
• Type：Gear Reducer
• Power：3kw ~ 5000kw
• Ratio：1,1.25 ~ 1,450
• Material：Cast Iron
• Input：Flange or Solid Shaft
• Output：Flange or Solid Shaft or Hollow Shaft
• Output Torque：3 ~ 900kn.M
• Transport Package：Wooden Case
• Specification：1-26
• Trademark：ANG Drive
• Origin：China
• HS Code：8483409000
• Production Capacity：3000PCS Per Month

ANG HB Industrial GearboxTypeHelical parallel shaft type, Bevel-helical right-angle typeModelH1/B1~H26/B26Input power3 ~ 5000 KW;Input speed750rpm ~ 1500rpmReduction ratio1/1.25 ~ 1/450Output torque 3 ~ 900kN.mInstall typeFoot / Solid shaft / Hollow shaft / Output flange…EfficiencySingle-stage 98%, 2-stage 96%, 3-stage 94%, 4-stage 92%Precision of gearAccurate grinding, class 6Design positionA / B / C / D / E / F / G / H / IAccessoriesBack stop / Cooling fan / Cooling coil / Oil pump / Compensation tank …
Typical Application

♦ Coal mining
♦ Power Plant Equipment
♦ Metallurgical Industry
♦ Metal Forming Machinery
♦ Petrochemical Industry
♦ Mining Machine
♦ Hoisting Machinery
♦ Cement and construction Industry
♦ Environmental Protection Industry
♦ Cable Industry
♦ Chemical industry
♦ Food Machinery

Models

Horizontal:
Parallel shaft gear unit box
H1SH1, H1SH3, H1SH5, H1SH7, H1SH9, H1SH11, H1SH13, H1SH15, H1SH17, H1SH19
H2SH, H2HH, H2DH, H2KH, H2FH, H3SH, H3HH, H3DH, H3HM, H3DM, H4SH, H4HH, H4DH, H4HM, H4DM

Bevel helical right angle gear unit
B2SH, B2HH, B2DH, B2HM, B2DM, B3SH, B3HH, B3DH, B3HM, B3DM, B4SH, B4HH, B4DH, B4HM, B4DM

Vertical:
Parallel shaft gear unit box
H2SV, H2HV, H2DV, H3SV, H3DV, H4SV, H4HV, H4DV, H4KV, H4FV

Bevel helical right angle gear unit
B2SV, B2HV, B2DV, B3SV, B3HV, B3DV, B4SV, B4HV, B4DV, B4KV, B4FV









FAQ
Q: Can you make the gearbox with customization?
A: Yes, we can customize per your request, like flange, shaft, configuration, material, etc.

Q: Do you provide samples?
A: Yes. Sample is available for testing.

Q: What is your MOQ?
A: It is 10pcs for the beginning of our business.

Q: What's your lead time?
A: Standard product need 5-30days, a bit longer for customized products.

Q: Do you provide technology support?
A: Yes. Our company have design and development team, we can provide technology support if you
need.

Q: How to ship to us?
A: It is available by air, or by sea, or by train.

Q: How to pay the money?
A: T/T and L/C is preferred, with different currency, including USD, EUR, RMB, etc.

Q: How can I know the product is suitable for me?
A: >1^ST confirm drawing and specification >2^nd test sample >3^rd start mass production.

Q: Can I come to your company to visit?
A: Yes, you are welcome to visit us at any time.

Q: How shall we contact you?
A: You can send inquiry directly, and we will respond within 24 hours.
