Stainless Steel Chain Drive Wire Mesh Belt
Anping County Dinghe Wire Mesh Co., Ltd.- Standard or Nonstandard：Nonstandard
- Application：Textile Machinery, Garment Machinery, Conveyer Equipment, Packaging Machinery, Electric Cars, Motorcycle, Food Machinery, Marine, Mining Equipment, Agricultural Machinery, Car
- Feature：Flame-Retardant, Anti-Static, Oil-Resistant, Cold-Resistant, Corrosion-Resistant, Heat-Resistant, Alkali-Resistant, Skid-Resistance, Wear-Resistant, Acid-Resistant, High Temperature-Resistance
- Tensile Strength：Strong
- Material：Carbon Steel
- Type：Steel
Base Info
- Model NO.：fgd
- Max Width：9m
- Sample for Wire Mesh Belt：Free
- Transport Package：Wooden Case
- Specification：1x20m
- Trademark：hxmesh
- Origin：China
- HS Code：73141400
- Production Capacity：1000m,Day
Description
https://jaclmery.en.made-in-china.com/product-list-1.html
Specification:
Specification:
| Type | Spiral wire pitch | Cross rod pitch | Spiral wire diameter | Cross wire diameter |
| BWCB-1 | 4mm | 4mm | 0.9mm to 1.2mm | 1.2mm to 1.6mm |
| BWCB-2 | 5mm | 6.4mm | 0.9mm to 1.2mm | 1.2mm to 1.6mm |
| BWCB-3 | 5mm | 5mm | 0.9mm to 1.6mm | 1.2mm to 1.6mm |
| BWCB-4 | 6mm | 6mm | 0.9mm to 1.6mm | 1.2mm to 1.6mm |
| BWCB-5 | 6mm | 8mm | 0.9mm to 1.2mm | 1.2mm to 1.6mm |
| BWCB-6 | 6mm | 10mm | 0.9mm to 1.6mm | 1.2mm to 1.6mm |
| BWCB-7 | 8mm | 12mm | 1.2mm to 2.0mm | 1.2mm to 2.5mm |
| BWCB-8 | 8mm | 13mm | 1.2mm to 2.0mm | 1.2mm to 2.5mm |
Features:
- Quality cross rods with larger diameter than spiral wires for higher durability.
- Never creep to either side.
- Temperature range: -50°C to 1100°C.
- Quick and easy to install.
- Simple maintenance by replacing the broken parts easily.
- Resistant to acid, alkaline, chemical, abrasion and corrosion.
- Simple structure with smooth conveying surface.
- Long service life.
- Minimum maintenance.
- Complying with food safety standards such as FDA, GMP and others up your request.
