Vertical Type Planetary Box Gear Reducer Motor Precision Measuring Instrument
Taibang Motor Industrial Group Co., Ltd.- Application：Machinery, Agricultural Machinery
- Function：Distribution Power, Change Drive Torque, Change Drive Direction, Speed Reduction
- Layout：Cycloidal
- Hardness：Hardened Tooth Surface
- Installation：Vertical Type
- Step：Double-Step
Base Info
- Type：Planetary Gear Box
- Geared Motor：Gpb090 Planetary Gearbox
- Transport Package：Carton
- Specification：GPB090
- Trademark：GPG
- Origin：Wenzhou
- HS Code：85014000
- Production Capacity：50000pic,Year
Description
Rotary Inertia1 3 0.03 0.16 0.61 3.25 9.21 28.98 69.61 4 0.03 0.14 0.48 2.74 7.54 23.67 54.37 5 0.03 0.13 0.47 2.71 7.42 23.29 53.27 6 0.03 0.13 0.45 2.65 7.25 22.75 51.72 7 0.03 0.13 0.45 2.62 7.14 22.48 50.97 8 0.03 0.13 0.44 2.58 7.07 22.59 50.84 9 0.03 0.13 0.44 2.57 7.04 22.53 50.63 10 0.03 0.13 0.44 2.57 7.03 22.51 50.56 2 15 0.03 0.03 0.13 0.13 0.47 0.47 2.71 7.42 23.29 20 0.03 0.03 0.13 0.13 0.47 0.47 2.71 7.42 23.29 25 0.03 0.03 0.13 0.13 0.47 0.47 2.71 7.42 23.29 30 0.03 0.03 0.13 0.13 0.47 0.47 2.71 7.42 23.29 35 0.03 0.03 0.13 0.13 0.47 0.47 2.71 7.42 23.29 40 0.03 0.03 0.13 0.13 0.47 0.47 2.71 7.42 23.29 45 0.03 0.03 0.13 0.13 0.47 0.47 2.71 7.42 23.29 50 0.03 0.03 0.13 0.13 0.44 0.44 2.57 7.03 22.51 60 0.03 0.03 0.13 0.13 0.44 0.44 2.57 7.03 22.51 70 0.03 0.03 0.13 0.13 0.44 0.44 2.57 7.03 22.51 80 0.03 0.03 0.13 0.13 0.44 0.44 2.57 7.03 22.51 90 0.03 0.03 0.13 0.13 0.44 0.44 2.57 7.03 22.51 100 0.03 0.03 0.13 0.13 0.44 0.44 2.57 7.03 22.51 Item Number of stage GB042 GB060 GB060A GB90 GB090A GB115 GB142 GB180 GB220 Backlash(arcmin) High Precision P0 1 ≤1 ≤1 ≤1 ≤1 ≤1 ≤1 2 ≤3 ≤3 ≤3 ≤3 Precision P1 1 ≤3 ≤3 ≤3 ≤3 ≤3 ≤3 ≤3 ≤3 ≤3 2 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 Standard P2 1 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5 2 ≤7 ≤7 ≤7 ≤7 ≤7 ≤7 ≤7 ≤7 ≤7 Torsional Rigidity(N.M/arcmin) 1 3 7 7 14 14 25 50 145 225 2 3 7 7 14 14 25 50 145 225 Noise(dB) 1,2 ≤56 ≤58 ≤58 ≤60 ≤60 ≤63 ≤65 ≤67 ≤70 Rated input speed(rpm) 1,2 5000 5000 5000 4000 4000 4000 3000 3000 2000 Max input speed(rpm) 1,2 10000 10000 10000 8000 8000 8000 6000 6000 4000
