Wpx90 Servo Planetary Reduction Gearbox
Profit Transmission Equipment Yancheng Co., Ltd.- Application：Machinery
- Function：Speed Changing, Speed Reduction
- Layout：Coaxial
- Hardness：Hardened Tooth Surface
- Installation：Vertical Type
- Step：Single-Step
Base Info
- Model NO.：WPX-90
- Type：Planetary Gear Box
- Transport Package：Wooden Cases or Cartons
- Specification：WPX-
- Trademark：SHENGHUI
- Origin：China
- HS Code：8483409000
- Production Capacity：1000000
Description
TypeWPX-40 WPX-60 WPX-90 WPX-115 WPX-142 WPX-190 Ratio Stages T2N
Rated output torque
(Nm) 5 12.5 37 100 310 1485 3 1 10 28 76 200 605 1780 4 9 24 62 140 420 1345 5 5 15 37 90 270 745 7 6 9 20 45 120 905 10 6 15.5 42 112 340 1070 9 2 6 15.5 42 112 340 1485 15 12 34.5 90 235 680 2035 20 10.5 29 70 155 460 1485 25 12 34.5 90 235 680 2035 30 9 24 62 140 590 1450 35 10.5 29 70 155 460 1485 40 9 24 50 112 340 1070 50 6 17 41 96 308 840 70 6 17 41 96 308 840 100 7.6 19 54 145 422 2590 64 3 15.5 44 110 295 895 2590 80 15.5 44 110 295 895 2590 100 15.5 44 110 295 895 2590 150 13.5 38 89 195 580 1855 200 15.5 44 110 295 895 2596 250 13.5 38 89 195 580 1855 350 10.5 30 50 145 515 1450 400 7.5 22 52 124.5 400 1070 500 7.5 22 52 124.5 400 1070 700 7.5 22 52 124.5 400 1070 1000 emergency stop torque T2not=2T2N Rotational inertia
(kgm2) 0.031 0.0135 0.77 2.63 12.14 15.6 3 1 0.022 0.093 0.52 1.79 7.78 16.3 4 0.019 0.078 0.45 1.53 6.07 15.4 5 0.017 0.065 0.39 1.32 4.63 16.1 7 0.016 0.065 0.39 1.32 4.63 15.2 10 0.03 0.131 0.74 2.62 12.14 15.9 9 2 0.023 0.077 0.71 2.53 12.35 15 15 0.019 0.075 0.44 1.5 6.65 15.7 20 0.019 0.075 0.44 1.49 5.81 15.3 25 0.017 0.064 0.39 1.3 6.36 15.2 30 0.016 0.064 0.39 1.3 5.28 16.1 35 0.016 0.064 0.39 1.3 5.28 15.2 40 0.016 0.064 0.39 1.3 4.5 15.2 50 0.016 0.064 0.39 1.3 4.5 15.2 70 0.016 0.058 0.31 1.12 3.53 15.2 100 0.019 0.075 0.5 1.5 7.5 15.4 80 3 0.019 0.075 0.44 1.49 7.4 15.4 100 0.016 0.064 0.39 1.3 6.5 15.2 150 0.016 0.064 0.39 1.3 6.2 15.2 200 0.016 0.064 0.39 1.3 5.7 15.2 250 0.016 0.064 0.39 1.3 5.4 15.2 350 0.016 0.064 0.39 1.3 5.4 15.2 400 0.016 0.064 0.39 1.3 5.2 15.2 500 0.016 0.064 0.39 1.3 5.2 15.2 700 0.016 0.064 0.39 1.3 5.2 15.2 1000 backslash
(arcmin) reduced <5 <3 <3 <3 <5 <10 1 standard <10 <8 <8 <8 <10 <15 reduced <8 <5 <5 <5 <8 <15 2 standard <12 <10 <10 <10 <10 <18 reduced <10 <8 <8 <8 <10 <18 3 standard <15 <12 <12 <12 <15 <22 torsional rigidity
(Nm/arcmin) 0.7 1.8 4.4 9.2 26.7 66.7 noise dB(A) 55 58 60 65 70 75 Max.input speed 10000 8000 6000 6000 5000 3500 1-min Rated input speed 4500 4000 4000 3500 2000 1500 1-min Max.Radialforce(N) 185 265 400 1240 3700 6700 Stages Max.Axialforce(N) 150 200 420 1000 3500 3800 Full-load efficiency(%) 96 1 94 2 90 3 service life (H) 20000 Weight (Kg) 0.9 2.1 6.4 13 25 50 1 1.2 2.5 7.8 14.5 28 55 2 1.5 2.9 9.2 16 31 60 3
Rated output torque
(Nm)
(kgm2)
(arcmin)
(Nm/arcmin)
