ZD MOTOR 40W Brushless DC Gear Motors
Ningbo Zhongda Leader Intelligent Transmission Co., Ltd.- Application：Motor, Motorcycle, Machinery, Agricultural Machinery
- Function：Change Drive Torque, Speed Changing, Speed Reduction
- Layout：Cycloidal
- Hardness：Soft Tooth Surface
- Installation：Horizontal Type
- Step：Double-Step
Base Info
- Model NO.：Z4BLD40-4GN-25S(4GN30RC)
- Type：Cylindrical Gear Box
- Transport Package：CTN
- Specification：CCC, CE, UL. RoHS
- Trademark：ZDMOTOR
- Origin：Cixi, Zhejiang, China
- HS Code：8501310000
- Production Capacity：30000PCS,Month
Description
4GN()K
3-18
20~200
43.5
•Enter the gear ratio in the box () within the model name
•Z4BLD40-4GN-25S(4GN30RC) Machine Allowable Torque (Unit: N.m)Model
Motor Speed/Reduction Ratio
3
3.6
5
6
7.5
9
10
12.5
15
18
20
25
30
36
50
60
75
90
100
120
150
180
200
200~1500RPM
0.72
0.87
1.21
1.45
1.81
2.17
2.41
3.02
3.62
4.34
4.35
5.44
6.53
7.83
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
Z4BLD40-()GN
2000RPM
0.70
0.84
1.16
1.39
1.74
2.09
2.32
2.90
3.48
4.18
4.64
5.23
6.27
7.52
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
2500RPM
0.56
0.67
0.93
1.11
1.39
1.67
1.86
2.32
2.78
3.34
3.71
4.18
5.02
6.02
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
8.00
Note :The() (gray) in the table indicates that the rotation direction is consistent with the motor.(The torque under different speed and speed ratio is obtained under the ZD standard.)
•L Type Speed Reducer
•Z4BLD40-4GN-25S(4GN30RC) Machine Allowable Torque (Unit: N.m)
Motor Speed/Reduction Ratio
5
10
15
20
30
50
100
200
200~1500RPM
1.21
2.41
3.62
4.83
6.53
10.9
21.8
39.3
2000RPM
1.02
2.04
3.06
4.08
5.52
9.20
18.4
33.3
2500RPM
0.83
1.67
2.51
3.35
5.02
8.37
16.7
30.3
Note :All gearbox output turn direction in form are opposite as motor turn direction.(The torque under different speed and speed ratio is obtained under the ZD standard.)
Company Information
FAQ
Q: What're your main products?
A: We currently produce Brushed Dc Motors, Brushed Dc Gear Motors, Planetary Dc Gear Motors, Brushless Dc Motors, Stepper motors, Ac Motors and High Precision Planetary Gear Box etc. You can check the specifications for above motors on our website and you can email us to recommend needed motors per your specification too.
Q: How to select a suitable motor?
A:If you have motor pictures or drawings to show us, or you have detailed specs like voltage, speed, torque, motor size, working mode of the motor, needed lifetime and noise level etc, please do not hesitate to let us know, then we can recommend suitable motor per your request accordingly.
Q: Do you have a customized service for your standard motors?
A: Yes, we can customize per your request for the voltage, speed, torque and shaft size/shape. If you need additional wires/cables soldered on the terminal or need to add connectors, or capacitors or EMC we can make it too.
Q: Do you have an individual design service for motors?
A: Yes, we would like to design motors individually for our customers, but it may need some mold developing cost and design charge.
Q: What's your lead time?
A: Generally speaking, our regular standard product will need 15-30days, a bit longer for customized products. But we are very flexible on the lead time, it will depend on the specific orders.
Please contact us if you have detailed requests, thank you !
