• Model NO.：JMI
• Material：Cast Iron
• Type：Diaphragm Coupling
• Delivery Time：Depend on Your Quantity
• Transport Package：Depend on Your Quantity
• Specification：as your requirement
• Trademark：Huading
• Origin：China
• HS Code：8483600090
• Production Capacity：10000pieces,Year

NO	Tn    /N·m	Tmax  /N·m	[n]  /r·mi -1	d  (H7)					D	C  N·m/rad	t	I  kg·m 2  ≈	m  /kg  ≈
					Y	J,J1,  Z		L
					L	L	L1
JMI1	25	80	6000	14	32	-	J1  27 Z1 20	35	90	1×10 4	8.8	0.0007	1
				16,18,19	42		30
				20,22	52		38
JMI2	63	180	5000	18,19	42	-	30	45	100	1.4×10 4	9.5	0.001	1.3
				20,22,24	52		38
				25	62		44
JMI3	100	315	5000	20,22,24	52	-	38	50	120	1.87×10 4	11	0.0024	2.3
				25,28	62		44
				30	82		60
JMI4	160	500	4500	24	52	-	38	55	130	3.12×10 4	12.5	0.0037	3.3
				25,28	62		44
				30,32,35	82		60
JMI5	250	710	4000	28	62	-	44	60	150	4.32×10 4	14	0.0083	5.3
				30,32,35,38	82		60
				40	112		84
JMI6	400	1120	3600	32,35,38	82	82	60	65	170	6.88×10 4	15.5	0.0159	8.7
				40,42,45  ,48,50	112	-	84
JMI7	630	1800	3000	40,42	112	112	84	70	210	10.35×10 4	19	0.0432	14.3
				45,45,50  ,55,56		-
				60	142		107
JMI8	1000	2500	2800	45,48	112	112	84	80	240	16.11×10 4	22.5	0.0879	22
				50,55,56		-
				60,63,65,70	142		107
JMI9	1600	4000	2500	55,56	112	112	84	85	260	26.17×10 4	24	0.1415	29
				60,63,65  ,70,71,75	142	-	107
				80	172		132
JMI10	2500	6300	2000	63,65,70  ,71,75	142	142	107	90	280	7.88×10 4	17	0.2974	52
				80,85,90,95	172	-	132
JMI11	4000	9000	1800	75	142	142	107	95	300	10.49×10 4	19.5	0.4782	69
				80,85,90,95	172	-	132
				100,110	212		167
JMI12	6300	12500	1600	90,95	172	-	132	120	340	14.07×10 4	23	0.8067	94
				100,110  ,120 ,125	212		167
JMI13	10000	18000	1400	100,110  ,120,125	212	-	167	135	380	19.23×10 4	28	1.7053	128
				130,140	252		202
JMI14	16000	28000	1200	120,125	212	-	167	150	420	30.01×10 4	31	2.6832	184
				130,140,150	252		202
				160	302		242
JMI15	25000	40000	1120	140,150	252	-	202	180	480	47.46×10 4	37.5	4.8015	263
				160,170,180	302		242
JMI16	40000	56000	1000	160,170,180	302	-	242	200	560	68.09×10 4	41	9.4118	384
				190,200	352		282
JMI17	63000	80000	900	190,200,220	352	-	282	220	630	101.3×10 4	47	18.3753	561
				240	410		330
JMI18	100000	125000	800	220	352	-	282	250	710	161.4×10 4	54.5	28.2033	723
				240,250,260	410		330
JMI19	160000	200000	700	250,260	410	-	330	280	800	79.3×10 4	48	66.5813	1267
				280,300,320	470		380

       Our company supplies different kinds of products. High quality and reasonable price. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.


Our Services
24 hours online service
Enquiry will be replied in 2 hours
Factory Address:
No. 11, Fuyang Road, ChengNan Industrial Park, Jingjiang, Taizhou, Jiangsu, China
FAQ
1. Are u a manufacturer?
We are a professional manufacturer specializing in manufacturing cardan shaft and various series of couplings. We supply couplings for the wholesalers and dealers from different countries.
2. Can you do OEM?
 Yes, we can. We can do OEM & ODM for all the customers with customized artworks of PDF or AI format.
3. How does your factory do regarding quality control?
Quality is priority! We always attach great importance to quality controlling from the very beginning to the very end:
1) Firstly, we have specialized QC department to control the quality, and we also accept the third official government to inspect the cargoes before delivery.
2) Secondly, we have all detailed records for nonconformity products, then we will make summary according to these records, avoid it happen again.
3) Thirdly, We do observe the relevant codes of conduct & laws from government in environment, human right aspects like no children labor, no prisoner labor and so on.
 4. How can I get samples?
We are appreciated that new clients pay for the express fee for samples and this charge will be deducted once orders are released.
Products ListTransmission Machinery Parts NameModeluniversal couplingWS  WSD  WSPcardan shaftSWC  SWP  SWZtooth couplingCL  CLZ  GCLD  GIICL  GICL  NGCL  GGCL PGCLKdisc couplingJMI   JMIJ   JMII    JMIIJhigh flexible couplingLMchain couplingGLjaw couplingLTgrid couplingJSWelcome to customize products from our factory and pls send us more details about your purchasing.
Thank you for your time and attention.
