• Model NO.：RV063-60-90B5
• Type：Worm Gear Box
• Color：Ral5010&Blue &Other
• Size：030-150
• Ratio：7.5-100
• Input Flange Size：Blue and Silver
• Toothed Portion Shape：Worm and Shaft
• Transport Package：Wooden Case, Plywood Case ,Carton
• Specification：CE, SGS, TUV
• Trademark：Starshine Drive
• Origin：Foshan, Guangdong, China
• HS Code：8483409000
• Production Capacity：20000 PCS Per Month

Basic Info.

Model NO. RV063-60-90B5 Type Worm Gear Box Color Ral5010&Blue &Other Size 030-150 Ratio 7.5-100 Input Flange Size Blue and Silver Toothed Portion Shape Worm and Shaft Transport Package Wooden Case/ Plywood Case /Carton Specification CE, SGS, TUV Trademark Starshine Drive Origin Foshan, Guangdong, China HS Code 8483409000 Production Capacity 20000 PCS Per Month

Product Description

1.
1.  Size: 030-040-050-060-075-090-105-110-130-150
2.   Power : 0.06 to 15 kW
3.   Reduction ratios:  between 5 and 100
4.   Cases:  up to 105 in die-cast aluminum alloy , and over 105 in HT200 gray cast iron
5.   Worm wheel: KK alloy (patent material)
6.   Aluminum units are supplied complete with synthetic oil
7.  Worm gear reducers are available with different combinations: NMRV+NMRV, NMRVpower+NMRV, NRV+NMRV, NRVpower+NMRV, PC+NMRV,NMRV+JWB


2.

Date Size	Ratio	Power range(KW)
RV030	5~80	0.06~0.18
RV040	5~100	0.09~0.37
RV050	5~100	0.12~0.75
RV063	5~100	0.18~1.5
RV075	7.5~100	0.25~4.0
RV090	7.5~100	0.37~4.0
RV105	7.5~100	0.55~7.5
RV110	7.5~100	0.55~11
RV130	7.5~150	0.75~11
RV150	7.5~100	1.5~11
