Ngcl Type Drum Type Gear Coupling with Brake Wheel
Jingjiang Huading Machinery Manufacturing Co., Ltd.- Shaft Hole：22~250
- Torque：355n. M - 100000n. M
Base Info
- Model NO.：NGCL
- Bore Diameter：42mm
- Speed：3800(R,M)
- Structure：Flexible
- Material：42CrMo
- Type：Brake Wheel
- Color：Customer Required
- Application：Industry
- Delivery Time：Depend on Your Quantity
- Transport Package：Depend on Your Quantity
- Specification：as your requirement
- Trademark：Huading
- Origin：China
- HS Code：8483600090
- Production Capacity：5000pieces,Year
- Package size per unit product：880.00cm * 850.00cm * 960.00cm
- Gross weight per unit product：60.000kg
Description
Product Parameters
| Model | Tn N·m | Y,J1,Z1 | DO | D | D1 | C | C1 | H | B3 | Kg | |
| dz,d1,d2 | L | ||||||||||
| NGCL1 | 355 | 20-35 | 38-82 | 160 | 103 | 71 | 30 | 8 | 2.0 | 68 | 7.3 |
| NGCL2 | 630 | 25-45 | 44-112 | 160 | 115 | 83 | 36 | 8 | 2.0 | 68 | 9.7 |
| NGCL3 | 1000 | 28-56 | 44-112 | 200 | 127 | 95 | 41 | 8 | 2.0 | 85 | 15.2 |
| NGCL4 | 1600 | 38-65 | 60-142 | 200 | 149 | 116 | 41 | 8 | 2.0 | 85 | 21.4 |
| NGCL5 | 2800 | 40-75 | 84-142 | 250 | 167 | 134 | 48 | 8 | 2.5 | 105 | 33.1 |
| NGCL6 | 4500 | 45-90 | 84-172 | 250 | 187 | 153 | 49 | 9 | 2.5 | 105 | 38.5 |
| NGCL7 | 6300 | 50-100 | 84-212 | 315/(300) | 204 | 170 | 53 | 9 | 2.5 | 132 | 61.8 |
| NGCL8 | 9000 | 55-110 | 84-212 | 400 | 230 | 186 | 64 | 12 | 3.0 | 168 | 96.5 |
| NGCL9 | 14000 | 60-130 | 107-252 | 500 | 256 | 212 | 71 | 13 | 3.0 | 210 | 151 |
| NGCL10 | 20000 | 65-150 | 107-252 | 630/(600) | 287 | 239 | 65 | 15 | 3.5 | 265 | 209 |
| NGCL11 | 31500 | 70-170 | 107-302 | 710/(700) | 325 | 276 | 77 | 16 | 3.5 | 298 | 300 |
| NGCL12 | 45000 | 75-200 | 107-352 | 710/(700) | 362 | 313 | 94 | 17 | 4.0 | 298 | 384 |
| NGCL13 | 63000 | 150-220 | 202-352 | 800 | 412 | 350 | 88 | 18 | 4.5 | 335 | 544 |
| NGCL14 | 100000 | 170-250 | 242-410 | 800 | 462 | 420 | 92 | 20 | 5.5 | 335 | 736 |
Detailed Photos
Company ProfileAfter Sales ServiceFAQ
Q 1: Are you trading company or manufacturer?
A: We are a professional manufacturer specializing in manufacturing
various series of couplings.
Q 2:Can you do OEM?
Yes, we can. We can do OEM & ODM for all the customers with customized artworks of PDF or AI format.
Q 3:How long is your delivery time?
Generally it is 20-30 days if the goods are not in stock. It is according to quantity.
Q 4: Do you provide samples ? Is it free or extra ?
Yes, we could offer the sample but not for free.Actually we have a very good price principle, when you make the bulk order then cost of sample will be deducted.
Q 5: How long is your warranty?
A: Our Warranty is 12 month under normal circumstance.
Q 6: What is the MOQ?
A:Usually our MOQ is 1pcs.
Q 7: Do you have inspection procedures for coupling ?
A:100% self-inspection before packing.
Q 8: Can I have a visit to your factory before the order?
A: Sure,welcome to visit our factory.
Q 9: What's your payment?
A:1) T/T. 2) L/C
