• Model NO.：STANDARD
• Toothed Portion Shape：Spur Gear
• Type：Circular Gear
• Model：35-240
• Teeth：10-60t
• Surface：Zinc Plated, Blacken
• Heat Treatment：Case Harden
• Process：Machined, Forged
• Manipulate Way：Forced Manipulation
• Changes Way：Stepped
• Transport Package：Standard Sea Worthy Package
• Specification：ISO
• Trademark：MW
• Origin：China
• HS Code：848390000
• Production Capacity：100000PCS,Day

Basic Info.

Model NO. STANDARD Toothed Portion Shape Spur Gear Type Circular Gear Model 35-240 Teeth 10-60t Surface Zinc Plated, Blacken Heat Treatment Case Harden Process Machined, Forged Manipulate Way Forced Manipulation Changes Way Stepped Transport Package Standard Sea Worthy Package Specification ISO Trademark MW Origin China HS Code 848390000 Production Capacity 100000PCS/Day

Product Description

Standard sprocket wheel with hub
We are main supplier of all kind of industry sprocket, industrial chain sprocket, chain sprockets, wheel, sprockets wheel, sprocket, motorcycle wheel, special sprockets, agricultural sprocket, auto sprocket, car sprocket, agricultural sprocket, truck sprocket, stainless steel sprocket, crank wheel, double sprockets and so on. OEM customer welcomed!
Our sprocket is produced by CNC machines and quality well controlled
Each kind of standard sprocket product
1. Rang of products
03/04/05B/06B/08B/10B/12B/16B/20B/24B/28B/32B
25/35/40/41/50/60/80/100/120/140/160/180/200/240
2. Max. Processing diameter: ø =1450mm
The series of finished-bore sprockets
1. Rang of product
06B/08B/10B/12B/16B/20B/
35/40/41//50/60/80/100/120/140/160
2. Max. Processing diameter: ø =1450mm
Taper bore sprocket of BTL serie
1. Rang of product
06B/08B/10B/12B/16B/20B
35/40/41//50/60/80/100/120/140/160
2. Max. Processing diameter: ø =1450mm.
Max. Coordinated taper bush: 8065
Taper bore sprocket of QTL serie
1. Rang of products
35/40/41//50/60/80/100/120/140/160/200
2. Max. Processing diameter: ø =1450mm.
Max. Coordinated QD cover: N
STL taper bore sprocket
1. Rang of product
35/40/41//50/60/80/100/120/140/160/200
2. Max. Processing diameter: ø =1450mm.
Max. Coordinated Browning cover: U2
Molten sprocket wheel
1. Rang of product
06B/08B/10B/12B/16B/20B/24B(technological-bore & BTL taper bore)
We feel honoured to offer made to order product.
2. Max. Processing diameter: ø =1450mm. Max. Coordinated taper
Bush: 5050
3. Max. Weight of the casting 2000kg.
Coarse pitch conveyor sprockets
1. Rang of product
P50/P75/P100/P50.8
BTL taper bore sprocket of standard series
1. Rang of product
06B/08B/10B/12B/16B/20B
35/40/50/60/80/100/120/140/160
Flat-top conveyor sprocket
1. Rang of product
P 1/2"
Idle gear
1. Rang of products
06B/08B/10B/12B/16B
35/40/41/50/60/80
Worm wheels &Worms
1. Rang of product( Module M1M3, Pressure angle20°
2. Rang of product( diametral pitch 4DP16PD,
Pressure angle14.5°
Cylindrical spur gears
1. Rang of product( Module M1M6, Pressure angle20° Pierce
2. Rang of product( diametral pitch 4DP16PD, Pressure angle20° /14.5° . STL taper bore
Straight bevel gear
1. Rang of product( Module M1.5M5, Pressure angle20° Pierce
2. Rang of product( diametral pitch 4DP16PD, Pressure angle20° /14.5° STL taper bore

TYPE	04B-48B
STANDARD	American,European Standard
MATERIAL	STEEL
SURFACE TREATMENT	BLACKEN ,ZINC PLATED
HEAT TREATMENT	HARDEN

Hangzhou Ocean Industry Co., Ltd. is a specialized supplier of a full range of sprockets.

Due to our sincerity in offering best service to our clients, understanding of your needs and overriding sense of responsibility toward filling ordering requirements, we have obtained the trust of buyers worldwide. Having accumulated precious experience in cooperating with foreign customers, our products are selling well in the American, European, South American and Asian markets.Our products are manufactured by modern computerized machinery and equipment. Meanwhile, our products are manufactured according to high quality standards, and complying with the international advanced standard criteria.

With many years' experience in this line, we will be trusted by our advantages in competitive price, one-time delivery, prompt response, on-hand engineering support and good after-sales services.

Additionally, all our production procedures are in compliance with ISO9001 standards. We also can design and make non-standard products to meet customers' special requirements. Quality and credit are the bases that make a corporation alive. We will provide best services and high quality products with all sincerity. If you need any information or samples, please contact us and you will have our soon reply.
