• Model NO.：PMB7.5 PMP7.5sp
• Production Capacity：500000 Pieces Per Month

Basic Info.

Model NO. PMB7.5 PMP7.5sp Production Capacity 500000 Pieces Per Month

Product Description

Concrete Mixer Truck PMB7.5 PMP7.5sp Reducer Construction Machinery Spare Parts



Product Description:


PMP is today the acknowledged world leader in the production ofgearboxes for concrete mixer trucks.

The reasons behind this success are the simple and solid design, theconstant selection of the best materials and the attention to details;as a result PMB gearboxes constantly exceed customers' expectationfor durability, efficiency and serviceability.

ELEPHANT Fluid Power is a hydraulic power expert integrating professional concrete mixer (pump truck) hydraulic system supporting, maintenance and spare parts supply.
  The company has long-term supply of PMP7.5sp reducer assembly, mixer truck PMP imported reducer bearing oil seal, PMP7.5sp reducer bearing oil seal, PMP6.5S/PMP7.0S/PMP7.5sp reducer and accessories, mixer truck reducer, Italy Reducer, PMP special bearing oil seal, specific models 800730, 801806, 809280, 40779, 540626AA, 579905A, 579905AA, 801215A, 804312A, bs2B248180, 540626AA. J30CNF, etc.

Main models: 6SP reducer assembly, 7SP reducer assembly, PMB6R100 reducer assembly and accessories PMP reducer assembly and accessories: primary/secondary input shaft, housing, sun gear, planetary gear, planet carrier, bearing 248180, various oil seals, various filter elements.

One: PMB6SP-Max Output torque: 60000 Reduction ratio i: 99.9 Maximum output speed (rpm): 2500 Drum mixing capacity (m3) 8 Weight (kg): 270 Lubricating oil capacity (liter): 12 Drum flange Maximum dynamic turntable angle: +/-6 Two: PMB7SP-maximum output torque: 70000 reduction ratio i: 120.3 maximum output speed (rpm): 2500 drum stirring capacity (m3): 9-10 weight (kg): 290 lubricant capacity (liter): 13 drum flange maximum Dynamic turntable angle: +/-6 3:PMB7bSP-Maximum output torque: 70000 Reduction ratio i: 121.6, 100.7, 129.1 Maximum

output speed (rpm): 2500 Drum stirring capacity (m3): 10-12 Weight (kg): 342 Lubricating oil capacity (liter): 15 roller flange maximum dynamic turntable angle: +/-6


Attribute:


Attribute	Specifications
Material	Cast/Ductile iron, steel, bronze and others
Types	Construction machine
Function	Completely interchangeable with original pump
Parts name	Reducer
Processing technic	Cutting, lathe, machining center, heat treatment, grind, honing, burring and so on
Trademark	Elephant Fluid Power, Neutral label, or according to client's requirement
