• Model NO.：GFT070-35X50
• Material：Aluminum
• Type：Clamp Rigid Coupling
• OEM：Accept
• Market：Global
• Transport Package：Single Box or as Your Requirements
• Specification：P0
• Trademark：SUMA
• Origin：Changzhou, Jiangsu, China
• HS Code：84836000
• Production Capacity：100000PCS,Month

model parametercommon bore diameter d1,d2ΦDLLFLPMtightening screw torque
(N.M)GFT035-16X223,4.5,6,6.35,7,816227.257.5M30.7GFT050-50X275,6,7,8,9,10,11,12,12.7,14,15,16,17,18,19274415.513M41.7GFT070-35X508,10,11,12,12.7,14,15,16,17,18,19,20,22,355018.513M54GFT075-45X558,10,11,12,12.7,14,15,16,17,18,19,20,22,24,2545552113M54GFT090-55X5510,12,12.7,14,15,16,17,18,19,20,22,24,25,28,30,3255552113M54GFT095-55X6110,12,12.7,14,15,16,17,18,19,20,22,24,25,28,30,3255612413M54GFT100-66x8812,12.7,14,15,16,17,18,19,20,22,24,25,28,30,32,35,3866883518M810.5GFT110-85X11016,17,18,19,20,22,24,25,28,30,32,38,40,42,45851104422M1020model parameterRated torque
(N.M)*Maximum torque
(N.M)*maximum speed
rpmmoment of inertia
(Kg.M²)allowable eccentricity
(mm)*allowable deflection angle
(°)*allowable axial deviation
(mm)*weight(g)GFT035-16x222.55.0160000.38x10^-60.10.5±0.310GFT050-50X277.515120005.1x10^-60.21.0±0.560GFT070-35X5081690001.78x10^-50.21.0±0.5120GFT075-45X5512.52570005.35x10^-50.21.0±0.5210GFT090-55x55224460001.14x10^-40.31.0±0.5310GFT095-55x61224460001.14x10^-40.31.0±0.5358GFT100-66x88408050004.33x10^-40.31.0±0.7785GFT110-85X1107515040001.43x10^-30.31.0±0.71560
