Foot Mounted Planetary Gearbox with Solid Shaft

Shanghai SGR Heavy Industry Machinery Co., Ltd.
  • Application：Industry
  • Hardness：Hardened
  • Type：Circular Gear
  • Diameter：up to 885mm
  • Material：Cast Iron
  • Manipulate Way：Robotics

Base Info

  • Model NO.：MN3E446FO
  • Changes Way：Mixed
  • Manufacturing Method：Cut Gear
  • Toothed Portion Shape：Spur Gear
  • Transport Package：Plywooe Case or Stell Cage
  • Specification：ISO9001: 2008
  • Trademark：SGR
  • Origin：China
  • HS Code：8483409000
  • Production Capacity：400PCS,Month

Description

Basic Info.

Model NO. MN3E446FO Changes Way Mixed Manufacturing Method Cut Gear Toothed Portion Shape Spur Gear Transport Package Plywooe Case or Stell Cage Specification ISO9001: 2008 Trademark SGR Origin China HS Code 8483409000 Production Capacity 400PCS/Month

Product Description

Technical data:
1. Ratio range: 3.15-9000
2. Input power: 0.25-55KW
3. Permit torque rang: ≤ 800000N. M
4. Output speed: 0.425-445 r/min
5. Structure mode: Possibility of flange, foot, or shaft mounting solutions

Characteristic:
1. Wide and comprehensive range of N series for industrial applications
2. Low speed shaft design: Cylindrical with key, splined, hollow with shrink disc or splined hollow shaft
3. Rigid and precise nodular cast iron casing
4. Low noise running, high manufacturing quality standard
5. High and reliable performance, load capacity and low speed shaft bearing

Foot Mounted Planetary Gearbox with Solid Shaft
 Ratio 3.15:1 to 9000:1
 Reduction Stages up to 6 reduction stages in one gearbox
 Nominal Output Torque up to 800,000N.m
