• Model NO.：SRC01-SRC04
• Power：0.12kw-4kw
• Output Torque：3-601 N.M
• Model：Src01,Src02,Src03,Src04
• Transmission：Helical
• Reduction：Two-Staged
• Warranty：One Year and Free Technical Support
• Coupled Flange Type：B5 or B14
• Customised：Available for Flange and Shaft
• Foot Mounted：Available to Request
• Transport Package：1 Set , Carton, Several Cartons , Wooden Pallet
• Specification：ISO9001
• Trademark：Chenxin
• Origin：Zhejiang Taizhou
• HS Code：8483409000
• Production Capacity：10000 Per,Month

Input couplingFlange and shaftOutput couplingFlange and shaftFoot mounted Available for Motovario and Bonfiglioli foot mounted specs. The letter,B in the data sheet of foot code is for Bonfiglioli and M for Motovario Range of reduction ratios 3.74---51.30 Motor power coupled 0.12---4KW Version

1.Flange coupled,shaft output,with foot mounted,marked as SRC...P



2.Shaft coupled and output,with foot mounted,marked as SRC...HS




3.Flange coupled,shaft output,no foot mounted,marked as SRCZ...P



4.Shaft coupled and output,no foot mounted,marked as SRCZ...HS



5.Flange coupled and output,no foot mounted,marked as SRCF...P



6.Shaft coupled,flange output,no foot mounted,marked as SRCF...HS
