Straight Bevel Gears of Combine Parts Mod. 3 16t

Hangzhou Donghua Power Transmission Imp. & Exp. Co., Ltd.
  • Manufacturing Method：Cast Gear
  • Toothed Portion Shape：Bevel Wheel
  • Type：Bevel Gear
  • Mod：1 1.5 2 2.5 3 4
  • Transport Package：Export Package
  • Specification：DIN, ANSI, GB

Base Info

  • Model NO.：Mod. 3 16T
  • Trademark：DONGHUA
  • Origin：China
  • HS Code：84839000
  • Production Capacity：5000PCS,Month

Description

 Bevel GearGearSpline ISpline IIModuleMin1.51.5-Max5.04.0-Teeth NumberMin1630-Max3050-Pressure AngleMin17°20°-Max25°30°-Pitch AngleMin18°--Max56°--Spiral AngleMin20°--Max35°--O.DMin26--Max157--L(max) 200
Straight Bevel Gears of Combine Parts Mod. 3 16t
