Inline Planetary Gear Reducer with Flange Mounted
Shanghai SGR Heavy Industry Machinery Co., Ltd.- Application：Motor, Machinery, Marine, Agricultural Machinery, Industry
- Function：Distribution Power, Clutch, Change Drive Torque, Change Drive Direction, Speed Changing, Speed Reduction, Speed Increase
- Layout：Coaxial
- Hardness：Hardened Tooth Surface
- Installation：Horizontal Type
- Step：Double-Step
Base Info
- Model NO.：N2E281C1C20.81-112B5
- Type：Planetary Gear Box
- Material：Cast Iron
- Manipulate Way：Semi-Automatic Manipulation
- Changes Way：Mixed
- Manufacturing Method：Cut Gear
- Toothed Portion Shape：Bevel Wheel
- Transport Package：Plywood Case, Steel Cage
- Specification：80*75*90
- Trademark：SGR
- Origin：China
- HS Code：8483409000
- Production Capacity：400PCS,Month
Description
Basic Info.
Model NO. N2E281C1C20.81-112B5 Type Planetary Gear Box Material Cast Iron Manipulate Way Semi-Automatic Manipulation Changes Way Mixed Manufacturing Method Cut Gear Toothed Portion Shape Bevel Wheel Transport Package Plywood Case, Steel Cage Specification 80*75*90 Trademark SGR Origin China HS Code 8483409000 Production Capacity 400PCS/MonthProduct Description
Inline planetary gear reducer with flange mountedTechnical data:
1. Ratio range: 3.15-3000
2. Input power: 0.25-55KW
3. Permit torque rang: ≤200000N. M
4. Output speed: 0.425-445 r/min
5. Structure mode: Possibility of flange, foot, or shaft mounting solutions
Inline planetary gear reducer with flange mounted
Characteristic:
1. Wide and comprehensive range of N series for industrial applications
2. Low speed shaft design: Cylindrical with key, splined, hollow with shrink disc or splined hollow shaft
3. Rigid and precise nodular cast iron casing
4. Low noise running, high manufacturing quality standard
5. High and reliable performance, load capacity and low speed shaft bearing
| Ratio | 3.15:1 to 9000:1 |
| Reduction Stages | up to 6 reduction stages in one gearbox |
| Nominal Output Torque | up to 800,000N.m |
