ANSI Standard Bevel Gear M2.5

Hangzhou Donghua Power Transmission Imp. & Exp. Co., Ltd.
  • Application：Industry
  • Hardness：Hardened
  • Gear Position：External Gear
  • Manufacturing Method：Rolling Gear
  • Toothed Portion Shape：Bevel Wheel
  • Material：Cast Iron

Base Info

  • Model NO.：M2.5
  • Type：Bevel Gear
  • Pitch：6 8 10 12 14 16
  • Manipulate Way：Semi-Automatic Manipulation
  • Changes Way：Stepped
  • Transport Package：Export Package
  • Specification：DIN, ANSI, GB
  • Trademark：DONGHUA
  • Origin：China
  • HS Code：84839000
  • Production Capacity：5000PCS,Month

Description

Spiral Bevel GearGearSpline ISpline IIModuleMin1.51.5-Max5.04.0-Teeth NumberMin1630-Max3050-Pressure AngleMin17°20°-Max25°30°-Pitch AngleMin18°--Max56°--Spiral AngleMin20°--Max35°--O.DMin26--Max157--L(max) 200
