Big Torque Internal Splined Shaft Planetary Gear Speed Reducer, Gearmotor, Gearboxes with Foot

Shanghai SGR Heavy Industry Machinery Co., Ltd.
  • Application：Motor, Electric Cars, Machinery, Marine, Agricultural Machinery
  • Function：Change Drive Torque, Change Drive Direction, Speed Changing, Speed Reduction, Speed Increase
  • Layout：Coaxial
  • Hardness：Hardened Tooth Surface
  • Installation：Horizontal Type
  • Step：Four-Step

Base Info

  • Type：Planetary Gear Box
  • Transport Package：Wooden Case
  • HS Code：8483409000
  • Production Capacity：400PCS,Month

Description

AInput Component 1:AC electric motor 2: NEMA or IEC motor 3: NEMA or IEC motor adapter flange 4: the Solid input shaft 5: Solid input shaft with the fanBGear Reductions (co-axial stage 1-5 ,right angle 1-4 . ) 6:Right angle reduction stage 7: Planetary reduction stage 8: Worm/planetary combination 9: Bevel helical planetary combination  COutput Component  10: Flanged output/ Footed output-Solid shaft 11: Flanged output/ Footed output-Male spline shaft 12: Flanged output/ Footed output- Female spline shaft 13: Flanged output/ Footed output- 14: Flanged output/ Footed output-Pinion 15: Shaft Mount output for shrink discD Fittings 16: Flange 17: Pinion gear 18: Sleeve coupling 19: Endplate 20: Splined bar 21: Shrink disc



Big Torque Internal Splined Shaft Planetary Gear Speed Reducer, Gearmotor, Gearboxes with Foot

Big Torque Internal Splined Shaft Planetary Gear Speed Reducer, Gearmotor, Gearboxes with Foot
Big Torque Internal Splined Shaft Planetary Gear Speed Reducer, Gearmotor, Gearboxes with Foot
Big Torque Internal Splined Shaft Planetary Gear Speed Reducer, Gearmotor, Gearboxes with Foot
