High Power 200kw 500kw 90 Degree B Series Helical Gear Box Reduction Gearbox
Zhengzhou Aokman Machinery Co., Ltd.- Application：Machinery, Industry
- Function：Change Drive Torque, Speed Changing, Speed Reduction
- Layout：Right Angle
- Hardness：Hardened Tooth Surface
- Installation：Vertical Type
- Step：Double-Step
Base Info
- Model NO.：B
- Type：Circular Gear
- Ratio：I=1,1.25~1,450
- Input Speed：1500r,Min, 1000r,Min, 750r,Min
- Gear Arrangement：Helical Hardened Gearbox
- Rated Torque：0.79n.M~900kn.M
- Rated Power：4kw~3015kw
- Installation Form：Horizontal or Vertical
- Material：Cast Iron
- Manufacturing Method：Forging Gear
- Output Speed：1.7~1200rpm
- Color：Customized Color
- Gear Material：20crmnti Alloy Steel
- Mount Position：Horizontal , Vertical Mounted
- Input Form：Input Solid Shaft
- Output Form：Solid Shaft, Hollow Shaft
- Warranty：1 Year
- Transport Package：Wooden Case
- Specification：ISO
- Trademark：AOKMAN DRIVE
- Origin：China
- HS Code：8483409000
- Production Capacity：5000PCS,Year
Description
B Series Industrial Gearbox is a brand-new model of rigid tooth flank gear reducers which has the features as follows:
(1) B series industrial gearboxes have heavy load, large torque range, high-efficiency and long lifespan, high permissible axial and radial loads.
(2) B series orthogonal shaft gearbox has the features of low noise, high reliability and compact structure.
(3) Output shafts: Solid shaft or hollow shaft, and the hollow shaft can be attached with the shrink disk.
(4) Mounting type: horizontal, vertical.
Applications:
The products are widely applied in electricity, coal, cement, metallurgy, harbor, agriculture, shipping, lifting, environment protection, stage, logistic, weaving, paper making, light industry, plastics and other regions.
Material of Housing and Gear:
Materials
Technical data of B series helical gearbox:
If you have any demand for our products please feel free to contact me.
