Hc201 Marine Gearbox Advance

Hangzhou Advance Gearbox Group Co., Ltd.
  • Application：Marine
  • Type：Circular Gear
  • Color：as Shown in Figure
  • Manufacturing Method：Cast Gear
  • Toothed Portion Shape：Spur Gear

Base Info

  • Model NO.：HC201

Description

HC201 MARINE GEARBOX           MAX.500HP at 2500RPM
Engine Speed:1000~2500RPM
Ratio 2.46 2.955 3.526
Rate(hp/rpm) 0.20 0.20 0.180






L*W*H556*691*735mm
Bell housing:SAE0,1		 Net Weight350Kg
Flange:SAE 18,16,14

Options/CommentsMechanical or Electrical remote control.

Centre distance 205mm.
Engine6135ZLCa,NT-855-M400.
