Helical Hypoid Bevel Gear Units

Taizhou Sihai Machinery Co., Ltd.
  • Application：Motor
  • Function：Distribution Power, Change Drive Torque, Speed Changing, Speed Reduction
  • Layout：Cycloidal
  • Hardness：Hardened Tooth Surface
  • Installation：Oscillating Base Type
  • Step：Double-Step

Base Info

  • Model NO.：TKM
  • Type：Worm Gear Box
  • Ratio：60.5
  • Fs：1.1
  • Output Hole：25mm
  • IEC：71b5,B14
  • Color：Blue Silver
  • Material：Aluminum Alloy
  • Warranty：1year
  • Transport Package：1 PC , Carton, Several Cartons , Wooden Pallet
  • Trademark：chenxin
  • Origin：China
  • Production Capacity：5000PCS,Months

Description

Basic Info.

Model NO. TKM Type Worm Gear Box Ratio 60.5 Fs 1.1 Output Hole 25mm IEC 71b5/B14 Color Blue Silver Material Aluminum Alloy Warranty 1year Transport Package 1 PC / Carton, Several Cartons / Wooden Pallet Trademark chenxin Origin China Production Capacity 5000PCS/Months

Product Description

TKM  Helical hypoid bevel gears

TKM,TKB series helical gear units have more than 4 types. power 0.12~4kw, ratio7.48~302.5, torque 8~570Nm. Modulaw and multistructure can meet the demands of various conditions

1:Ground hardened helical gears

2:Modularity can be combined in many forms

3:Made of high quqlity aluminum alloy, light in weight and nonrusting

4:Large in output torque, high efficiency, ene-rgysaving and environmental protection

5:The mounting dimension of TKM series are compatible with SMRV series worm gear unit (a part of smrv050 dimensions are different from skm028)

6:The mounting dimension of SKB series are compatible with W series worm gear unit
