High Performance Aluminum Alloy Diaphragm Coupling

Jingjiang Huading Machinery Manufacturing Co., Ltd.

Standard Or Nonstandard：Standard
Shaft Hole：as Your Requirement
Torque：as Your Requirement
Bore Diameter：as Your Requirement
Speed：as Your Requirement
Structure：Flexible

Base Info

Model NO.：JMI
Material：45#Steel
Type：Diaphragm Coupling
Delivery Time：Depend on Your Quantity
Transport Package：Depend on Your Quantity
Specification：as your requirement
Trademark：Huading
Origin：China
HS Code：84836000
Production Capacity：10000pieces,Year

Description

Overview

Product Parameters

NO	Tn /N·m	Tmax /N·m	[n] /r·mi -1	d (H7)					D	C N·m/rad	t	I kg·m 2 ≈	m /kg ≈
					Y	J,J1, Z		L
					L	L	L1
JMI1	25	80	6000	14	32	-	J1 27 Z1 20	35	90	1×10 4	8.8	0.0007	1
				16,18,19	42		30
				20,22	52		38
JMI2	63	180	5000	18,19	42	-	30	45	100	1.4×10 4	9.5	0.001	1.3
				20,22,24	52		38
				25	62		44
JMI3	100	315	5000	20,22,24	52	-	38	50	120	1.87×10 4	11	0.0024	2.3
				25,28	62		44
				30	82		60
JMI4	160	500	4500	24	52	-	38	55	130	3.12×10 4	12.5	0.0037	3.3
				25,28	62		44
				30,32,35	82		60
JMI5	250	710	4000	28	62	-	44	60	150	4.32×10 4	14	0.0083	5.3
				30,32,35,38	82		60
				40	112		84
JMI6	400	1120	3600	32,35,38	82	82	60	65	170	6.88×10 4	15.5	0.0159	8.7
				40,42,45 ,48,50	112	-	84
JMI7	630	1800	3000	40,42	112	112	84	70	210	10.35×10 4	19	0.0432	14.3
				45,45,50 ,55,56		-
				60	142		107
JMI8	1000	2500	2800	45,48	112	112	84	80	240	16.11×10 4	22.5	0.0879	22
				50,55,56		-
				60,63,65,70	142		107
JMI9	1600	4000	2500	55,56	112	112	84	85	260	26.17×10 4	24	0.1415	29
				60,63,65 ,70,71,75	142	-	107
				80	172		132
JMI10	2500	6300	2000	63,65,70 ,71,75	142	142	107	90	280	7.88×10 4	17	0.2974	52
				80,85,90,95	172	-	132
JMI11	4000	9000	1800	75	142	142	107	95	300	10.49×10 4	19.5	0.4782	69
				80,85,90,95	172	-	132
				100,110	212		167
JMI12	6300	12500	1600	90,95	172	-	132	120	340	14.07×10 4	23	0.8067	94
				100,110 ,120 ,125	212		167
JMI13	10000	18000	1400	100,110 ,120,125	212	-	167	135	380	19.23×10 4	28	1.7053	128
				130,140	252		202
JMI14	16000	28000	1200	120,125	212	-	167	150	420	30.01×10 4	31	2.6832	184
				130,140,150	252		202
				160	302		242
JMI15	25000	40000	1120	140,150	252	-	202	180	480	47.46×10 4	37.5	4.8015	263
				160,170,180	302		242
JMI16	40000	56000	1000	160,170,180	302	-	242	200	560	68.09×10 4	41	9.4118	384
				190,200	352		282
JMI17	63000	80000	900	190,200,220	352	-	282	220	630	101.3×10 4	47	18.3753	561
				240	410		330
JMI18	100000	125000	800	220	352	-	282	250	710	161.4×10 4	54.5	28.2033	723
				240,250,260	410		330
JMI19	160000	200000	700	250,260	410	-	330	280	800	79.3×10 4	48	66.5813	1267
				280,300,320	470		380

Detailed Photos

Company Profile

After Sales Service

FAQ

Q 1: Are you trading company or manufacturer?
A: We are a professional manufacturer specializing in manufacturing
various series of couplings.

Q 2:Can you do OEM?
Yes, we can. We can do OEM & ODM for all the customers with customized artworks of PDF or AI format.

Q 3:How long is your delivery time?
Generally it is 20-30 days if the goods are not in stock. It is according to quantity.

Q 4: Do you provide samples ? Is it free or extra ?
Yes, we could offer the sample but not for free.Actually we have a very good price principle, when you make the bulk order then cost of sample will be deducted.

Q 5: How long is your warranty?
A: Our Warranty is 12 month under normal circumstance.

Q 6: What is the MOQ?
A:Usually our MOQ is 1pcs.

Q 7: Do you have inspection procedures for coupling ?
A:100% self-inspection before packing.

Q 8: Can I have a visit to your factory before the order?
A: Sure,welcome to visit our factory.

Q 9: What's your payment?
A:1) T/T. 2) L/C
