• Model NO.：FXJ-540
• Type：Planetary Gear Reducer
• Transport Package：Veneer Box
• Specification：FXJ300, 360, 400, 540, 720
• Trademark：FOSION
• Origin：China
• HS Code：40169990
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. FXJ-540 Type Planetary Gear Reducer Transport Package Veneer Box Specification FXJ300, 360, 400, 540, 720 Trademark FOSION Origin China HS Code 40169990 Production Capacity 50000PCS/Year

Product Description

Features of the reducer for FXJ mixer truck: The reducer for concrete mixer truck is used in the transmission system of the concrete mixer truck. The FOSION reducer adopts planetary gear transmission, with stable torque drive, compact structure, low maintenance and long life. The gear box body can be bolted to the mounting support of the frame, or directly connected to the frame, and connected to the drum through the output flange. The output flange can swing in a circle. The product structure and manufacturing process have reached international standards. Advanced level of similar products.

Reducer nameplate: Each FCL series reducer is equipped with a product nameplate, which is accurate, clear, and simple, and is used to identify the product.

FXJ-FOSION product code.

400, 540 (or 720) are one hundredth of the output torque N.m.
FXJ300 reducer-suitable for 2-4 square concrete mixer truck.
FXJ400 reducer-suitable for 4-6 square concrete mixer truck.
FXJ540 reducer-suitable for 6-8 square concrete mixer truck.
FXJ720 reducer-suitable for mixer trucks below 12 square meters.
Daily maintenance of the reducer: The first replacement of the lubricating oil of the reducer should be performed within the working hours of the mixer for about 200 hours or the vehicle running for no more than 30 days. After that, the lubricating oil will be replaced every 2000 hours, but the gear oil should be replaced at least once a year.
