• Type：Worm Gear Box
• Application Filed：CNC Machine
• Transport Package：Wooden Cases or Cartons
• Specification：GFB-
• Trademark：SHENGHUI
• Origin：China
• HS Code：8483409000
• Production Capacity：1000000

Basic Info.

Type Worm Gear Box Application Filed CNC Machine Transport Package Wooden Cases or Cartons Specification GFB- Trademark SHENGHUI Origin China HS Code 8483409000 Production Capacity 1000000

Product Description

R series helical gear reducer: It is a good versatility, combination, high bearing capacity reducer, it is not only very convenient to get a variety of different transmission ratio, and high efficiency, little vibration, and High radial load.

Performance and features:
1. The gear is made of high quality alloy carburizing and quenching, tooth surface hardness up to 60 ± 2 HRC, tooth surface grinding accuracy is as high as 5-6 level
2. The Gears are modified by computer modification technology, and greatly improving the carrying capacity of the reducer
3. From box body to gear, using fully modular structure design
4. Using CAD/CAM design and manufacturing, ensure the quality stability
5. Using a variety of sealing structure, to prevent oil spills
6. Low noise

Parameters:
1. Specifications: R/RF17, R/RF27, R/RF37, R/RF47, R/RF57, R/RF67, R/RF77, R/RF87, R/RF97, R/RF107, R/RF137, R/RF147, R/RF167
2. The output speed: 0.05 ~ 740 r/min
3. Output torque: 15000 nm
4. Electrical power: 0.18 ~ 132 kw
5. Installation forms: Foot flange installation
