Glts-82X98.1 Single Step Double Diaphragm Clamp Type Coupling

Changzhou Suma Precision Machinery Co., Ltd.
  • Standard Or Nonstandard：Standard
  • Shaft Hole：5-45
  • Torque：3-100
  • Bore Diameter：5-45
  • Speed：10000
  • Structure：Flexible

Base Info

  • Model NO.：GLTS-82x98.1
  • Material：Aluminum
  • Type：Clamp Rigid Coupling
  • Product Name：Gw Clamp Rigid Coupling Spring Coupling From Chang
  • OEM：Accept
  • Market：Global
  • Transport Package：Single Box or as Your Requirements
  • Specification：P0
  • Trademark：SUMA
  • Origin：Changzhou, Jiangsu, China
  • HS Code：84836000
  • Production Capacity：100000PCS,Month

Description

model parametercommon bore diameter d1common bore diameter d2DΦNLLF1LFSLPd3Mtightening screw torque
(N.M)smallestmaximumsmallestmaximumGLTS-34x42.95125153421.642.912.1514.253.59.5Φ16M31.5GLTS-39x50.2615619392550.215.1514.94.511.15Φ19M42.5GLTS-44x50.26186224429.650.215.1514.94.511.15Φ22.5M42.5GLTS-56x64.1824832563864.119.9019.755.513.45Φ32.5M57GLTS-68x75.610301038684675.62423.356.315.65Φ38.5M612GLTS-82x98.116381645825698.130.1530821.95Φ45M820model parameterRated torque
