Industrial Timing Edged Cogged Wrapped Rubber Raw Banded Auto Motorcycle Transmission Synchronous Tooth Drive Ribbed Poly Power V Belt

ZHEJIANG SANMEN SOUTH INDUSTRIAL CO., LTD.
  • Standard or Nonstandard：Standard
  • Application：Textile Machinery, Garment Machinery, Packaging Machinery, Auto Door
  • Feature：Flame-Retardant, Corrosion-Resistant, Heat-Resistant, High Temperature-Resistance
  • Tensile Strength：Strong
  • Material：Rubber
  • Type：Toothed Belt

Base Info

  • Model NO.：XL, L, H, XH, 3M, 5M, 8M, 14M
  • Belt Type：Open
  • Color：Black
  • Smell：No Smell
  • Width：Customerized
  • Transport Package：Carton or Weaved Bag
  • Specification：S8M-10MM
  • Trademark：SMSOUTH
  • Origin：Zhejiang
  • HS Code：40103900
  • Production Capacity：500000 M Per Week

Description

TYPE3M5M8M14M20MDouble synchronous belt height
                 hd3.205.308.2014.9021.20Single synchronous belt height
                 hs2.403.806.0010.0013.20Teeth height       ht1.222.063.386.028.40Pitch              Pb3.005.008.0014.0020.00Tooth apex Angle   ra0.871.492.464.506.50Fillet radius     rr0.24~0.300.40~0.440.64~0.761.20~1.351.77~2.01Dedendum width      S1.783.055.159.4014.00Tooth profile Angle
               2β≈14°14°14°14° 14°Section zenith distance  δ0.3810.5720.6861.3972.160
