• Model NO.：GF-65X80
• Material：Aluminum
• Type：Shaft Coupling
• OEM：Accept
• Market：Global
• Transport Package：Single Box or as Your Requirements
• Specification：P0
• Trademark：SUMA
• Origin：Changzhou, Jiangsu, China
• HS Code：84836000
• Production Capacity：100000PCS,Month

model parametercommon bore diameter d1,d2ΦDLLFLPFMtightening screw torque
(N.M)GF-14X223,4,5,6,6.35,7,8142214.36.63.8M 30.7GF-20X253,4,5,6,6.35,7,8,9,9.525,10,11202516.78.64M 30.7GF-20X303,4,5,6,6.35,7,8,9,9.525,10,11203019.258.65.3M 41.7GF-25X304,5,6,6.35,7,8,9,9.525,10,11,12,12.7,14,15253020.8211.65.6M 41.7GF-25X344,5,6,6.35,7,8,9,9.525,10,11,12,12.7,14,15253422.8211.65.6M 41.7GF-30X355,6,6.35,7,8,9,10,11,12,12.7,14,15,1630352311.55.75M 41.7GF-30X405,6,6.35,7,8,9,10,11,12,12.7,14,15,16304025.6011.510M 41.7GF-40X506,8,9,10,11,12,12.7,13,14,15,16,17,18,19,20,22,24405032.114.510M 54GF-40X556,8,9,10,11,12,12.7,13,14,15,16,17,18,19,20,22,24405534.514.510M 54GF-40X666,8.9,10,11,12,12.7,13,14,15,16,17,18,19,20.22,2440664014.512.75M 54GF-55X4912,12.7,14,15,16,17,18,19,20,22,24,25,28,30,3255493216.113.5M 68.4GF-55X7812,12.7,14,15,16,17,18,19,20,22,24,25,28,30,32557846.416.115.5M 68.4GF-65X8014,15,16,17,18,19,20,22,24,25,30,32,35,38,40,42,45658048.517.318.1M 810.5GF-65X9014,15,16,17,18,19,20,22,24,25,30,32,35,38,40,42,45659053.517.318.1M 810.5 model parameterRated torque
(N.M)*allowable eccentricity
(mm)*allowable deflection angle
(°)*allowable axial deviation
(mm)*maximum speed
rpmstatic torsional stiffness
(N.M/rad)High strength aluminum alloyPolyurethane imported from GermanyAnodizing treatment7GF-20X255.00.11±0.210000501.1x10^-613GF-20X305.00.11±0.210000531.0x10^-618GF-25X30100.11±0.210000905.0x10^-630GF-25X34100.11±0.210000905.0X10^-640GF-30X3512.50.11±0.2100001235.5x10^-646GF-30X4012.50.11±0.2100001235.5x10^-655GF-40X50170.11±0.2800011003.5x10^-5100GF-40X55170.11±0.2800011003.5x10^-5120GF-40X66170.11±0.2700011403.8x10^-5145GF-55X49450.11±0.2650022001.5x10^-3260GF-55X78450.11±0.2600025001.5x10^-3320GF-65X801080.11±0.2500048003.6x10^-3560GF-65X901080.11±0.2550045003.6x10^-3450
