Clamp Type Curved Jaw Coupling

Chengdu Unik Machinery Co., Ltd.
  • Standard Or Nonstandard：Standard
  • Structure：Flexible
  • Material：Carbon Steel
  • Type：Elastic Coupling
  • 92 Sh a：Yello Elastomer
  • 95/98 Sh a：Red Elastomer

Base Info

  • Model NO.：RGE-38
  • 64 Sh D-F：Green Elastomer
  • Transport Package：Blank Carton in Wooden Cases
  • Trademark：Ubet Machinery
  • Origin：China
  • HS Code：8483900000
  • Production Capacity：50, 000 Pieces,Month

Description

Item No.Finished bore rangeOutside DiameterNominal Torque NmUTJC-140-163015UTJC-190-254020UTJC-240-355570UTJC-280-4065190UTJC-380-4880380UTJC-420-5595530UTJC-480-62105620UTJC-550-74120820UTJC-650-801351250UTJC-750-951602560UTJC-900-1102004800

Ubet Jaw coupling grooving type is backlash free, using screws after slotting to eliminate the clearance. This grooving type coupling is suitable for power transmission on main shaft, elevating platform and machine tool.


Material: Alluminum for size below 42
               Steel for size over 42
Finish: Natural or Anodizing
Size Range: 19 to 75
Finished bore: according to ISO fit H7
Keyway width: according to DIN 6885/1
The Tolerance of keyway is Js9
