B Series 1: 20 Ratio 3 Stage Electric Motor Reduction Gearbox

Zhengzhou Aokman Machinery Co., Ltd.
  • Application:Machinery
  • Function:Change Drive Torque, Speed Changing, Speed Reduction
  • Layout:Helical
  • Hardness:Hardened Tooth Surface
  • Installation:Horizontal Type
  • Step:Double-Step

Base Info

  • Model NO.:H,B
  • Gear Housing:Casting Iron or Steel-Plate Welding Case
  • Installation Form:Horizontal or Vertical
  • Gear Arrangement:Helical Hardened Gearbox
  • Color:Red,Blue or Others
  • Quality Garantee:Europe CE Certification
  • Material:Cast Iron
  • Manufacturing Method:Forging, Grinding
  • Toothed Portion Shape:Helical Gear
  • Lubricant:Oil-Bath and Splash Lubrication
  • Warranty:1 Year
  • Input Speed:1500,1000,750rpm
  • Ratio:1.25~450
  • Gearing Arrangement:Helical
  • Output Torque:up to 900,000nm
  • Output Speed:1.7~1200rpm
  • Transport Package:Polywood Case
  • Specification:ISO
  • Trademark:AOKMAN DRIVE
  • Origin:China
  • HS Code:8483409000
  • Production Capacity:5000PCS,Year

Description

Overview Product Description

B Series 1: 20 Ratio 3 Stage Electric Motor Reduction Gearbox
1. Model Number

Types: H1,H2,H3,H4 Parallel Shaft Gearbox
Sizes: 1,2,3,4,5,24,25,26

2. Product Characteristics
(1)Large torque range, capable of horizontal mounting and vertical mounting.
(2)High-efficiency and long life-span, high permissible axial and radial loads.
(3)Low noise, high reliability and compact structure and so on.
(4)Output shafts type: solid shaft, hollow shaft and hollow shaft with shrink disk.
(5)Low noise, high reliability and compact structure.

DimensionsCustomization according to the application.

Rated Power:4KW~3015KW
Rated Torque:0.79N.m~900KN.m
Gear Arrangement:Helical Hardened Gearbox
Input Speed:1500r/min,1000r/min,750r/min
Housing:Casting iron or Steel-plate welding case
B Series 1: 20 Ratio 3 Stage Electric Motor Reduction Gearbox

Detailed Photos


3. DimensionsCustomization according to the application.

B Series Orthogonal Axis(Shaft) Gearbox (Bevel Helical Gears)
1.Model Number
Types: B2,B3,B4 Orthogonal Shaft Gearbox
Sizes: 1,2,3,4,5,24,25,26
2.Product Characteristics
B Series Industrial Gearbox is a brand-new model of rigid tooth flank gear reducers which has the features as follows:
(1) B series industrial gearboxes have heavy load, large torque range, high-efficiency and long lifespan, high permissible axial and radial loads.
(2) B series orthogonal shaft gearbox has the features of low noise, high reliability and compact structure.
(3) Output shafts: Solid shaft or hollow shaft, and the hollow shaft can be attached with the shrink disk.
(4) Mounting type: horizontal, vertical.
3. Technical Data
B Series 1: 20 Ratio 3 Stage Electric Motor Reduction Gearbox

Product Parameters


4. Technical Data



Packaging & Shipping

B Series 1: 20 Ratio 3 Stage Electric Motor Reduction Gearbox

Company Profile

B Series 1: 20 Ratio 3 Stage Electric Motor Reduction Gearbox

Our Advantages


B Series 1: 20 Ratio 3 Stage Electric Motor Reduction Gearbox

FAQ

1.Q:What kinds of gearbox can you produce for us?

A:Main products of our company: UDL series speed variator,RV series worm gear reducer, ATA series shaft mounted gearbox, X,B series gear reducer,
P series planetary gearbox and R, S, K, and F series helical-tooth reducer, more
than one hundred models and thousands of specifications
2.Q:Can you make as per custom drawing?
A: Yes, we offer customized service for customers.
3.Q:What is your terms of payment ?
A: 30% Advance payment by T/T after signing the contract.70% before delivery
4.Q:What is your MOQ?
A: 1 Set
If you have any demand for our products please feel free to contact me.
