Gsts-68X53.6 Aluminum Alloy Single Step Single Diaphragm Clamp Type Coupling

Changzhou Suma Precision Machinery Co., Ltd.
  • Standard Or Nonstandard：Standard
  • Shaft Hole：5-45
  • Torque：3-100
  • Bore Diameter：5-45
  • Speed：10000
  • Structure：Flexible

Base Info

  • Model NO.：GSTS-68x53.6
  • Material：Aluminum
  • Type：Clamp Rigid Coupling
  • Product Name：Gw Clamp Rigid Coupling Spring Coupling From Chang
  • OEM：Accept
  • Market：Global
  • Transport Package：Single Box or as Your Requirements
  • Specification：P0
  • Trademark：SUMA
  • Origin：Changzhou, Jiangsu, China
  • HS Code：84836000
  • Production Capacity：100000PCS,Month

Description

model parametercommon bore diameter d1common bore diameter d2DΦNLLF1LFSMtightening screw torque
(N.M)smallestmaximumsmallestmaximumGSTS-34x29.95125153421.629.912.1514.253.5M31.5GSTS-39x34.5615619392534.515.1514.94.5M42.5GSTS-44x34.56186224429.634.515.1514.94.5M42.5GSTS-56x45.1824832563845.119.9019.755.5M57GSTS-68x53.610301038684653.62423.356.3M612GSTS-82x68.116381645825668.130.15308M820model parameterRated torque
(N.M)*allowable eccentricity
(mm)*allowable deflection angle
(°)*allowable axial deviation
(mm)*maximum speed
rpmstatic torsional stiffness
(N.M/rad)High strength aluminum alloyS U S 3 0 4 Spring steelAnodizing treatment38GSTS-39x34.560.021±0.251000045001.49x10-569GSTS-44x34.590.021±0.301000052002.25x10-584GSTS-56x45.1250.021±0.4010000110007.23x10-5184GSTS-68x53.6600.021±0.4510000190002.02x10-4235GSTS-82x68.11000.021±0.5510000220005.95x10-4598
