L075, L090, L095, L100 Lovejoy L Type Flexible Coupling

Chengdu Unik Machinery Co., Ltd.
  • Standard Or Nonstandard：Standard
  • Structure：Flexible
  • Material：Carbon Steel
  • Type：Elastic Coupling
  • L075：L Type
  • L100：L Type

Base Info

  • Model NO.：L50, L070, L075, L090, L095, L100
  • Transport Package：Blank Carton in Wooden Cases
  • Trademark：Ubet Machinery
  • Origin：China
  • HS Code：8483900000
  • Production Capacity：50, 000 Pieces,Month

Description

SpecufucationTypeStd.boreMetric BoreInch BoreA(mm)B(mm)D(mm)E(mm)L035133-81/8-3/8"1620.56.6 L050165-153/16-5/8"2843.215.6 L070197-193/16-3/4"3550.819 L075199-253/16-1"4554.721 L090199-283/16-1 1/8"5454.721 L095199-283/8-1 1/8"5463.525.5 L09911212-357/16-1 3/8"64.572.527 L10011212-357/16-1 3/8"64.588.535 L11011515-481/2-1 7/8"8510843 L15011515-485/8-1 7/8"96115.445 L19021919-555/8-2 1/4"115133.454101.6L22521919-653/4-2 5/8"127153.464108


Ubet Jaw coupling grooving type is backlash free, using screws after slotting to eliminate the clearance.  This grooving type coupling is suitable for power transmission on main shaft, elevating platform and machine tool.


Material: Alluminum for size below 42
               Steel for size over 42
Finish: Natural or Anodizing
Size Range: 19 to 75
Finished bore: according to ISO fit H7
Keyway width: according to DIN 6885/1
The Tolerance of keyway is Js9


L075, L090, L095, L100 Lovejoy L Type Flexible Coupling
