Hexagon Timing Pulleys with Black Oxidated

Chengdu Unik Machinery Co., Ltd.
  • Pulley Sizes：Timing
  • Manufacturing Process：Sawing
  • Material：Aluminum
  • Surface Treatment：Zinc Coating
  • Application：Chemical Industry, Grain Transport, Mining Transport, Power Plant
  • Aluminum：Natual Anodized

Base Info

  • Model NO.：According to drawing
  • Steel：Black Oxidized
  • Cast Iron：Phosphated
  • Transport Package：in Fumigated Wooden Cases
  • Specification：Same quality as European brands
  • Trademark：Ubet Machinery
  • Origin：China
  • HS Code：8483900000
  • Production Capacity：100, 000 Pieces,Month

Description

Teeth ProfilePitchHTD3M,5M,8M,14M,20MATAT5,AT10,AT20TT2.5,T5,T10MXL0.08"(2.032MM)XL1/5"(5.08MM)L3/8"(9.525MM)H1/2"(12.7MM)XH7/8"(22.225MM)XXH1 1/4"(31.75MM)STS STPDS2M,S3M,S4.5M,S5M,S8M,S14MRPPRPP5M,RPP8M,RPP14M,RPP20MPGGTPGGT  2GT, 3GT and 5GTPCGTGT8M,GT14M
Types of pitches and sizes

Imperial Inch Timing Belt Pulley,
1.     Pilot Bore MXL025 for 6.35mm timing belt; teeth number from 16 to 72;
2.  Pilot Bore XL037 for 9.53mm timing belt; teeth number from 10 to 72;
3.  Pilot Bore, Taper Bore L050 for 12.7mm timing belt; teeth number from 10 to 120;
4.  Pilot Bore, Taper Bore L075 for 19.05mm timing belt; teeth number from 10 to 120;
5.  Pilot Bore, Taper Bore L100 for 25.4mm timing belt; teeth number from 10 to 120;
6.  Pilot Bore, Taper Bore H075 for 19.05mm timing belt; teeth number from 14 to 50;
7.  Pilot Bore, Taper Bore H100 for 25.4mm timing belt; teeth number from 14 to 156;
8.  Pilot Bore, Taper Bore H150 for 38.1mm timing belt; teeth number from 14 to 156;
9.  Pilot Bore, Taper Bore H200 for 50.8mm timing belt; teeth number from 14 to 156;
10.  Pilot Bore, Taper Bore H300 for 76.2mm timing belt; teeth number from 14 to 156;
11.  Taper Bore XH200 for 50.8mm timing belt; teeth number from 18 to 120;
12.  Taper Bore XH300 for 76.2mm timing belt; teeth number from 18 to 120;
13.  Taper Bore XH400 for 101.6mm timing belt; teeth number from 18 to 120;

Metric Timing Belt Pulley T and AT
1.  Pilot Bore T2.5-16 for 6mm timing belt; teeth number from 12 to 60;
2.   Pilot Bore T5-21 for 10mm timing belt; teeth number from 10 to 60;
3.   Pilot Bore T5-27 for 16mm timing belt; teeth number from 10 to 60;
4.   Pilot Bore T5-36 for 25mm timing belt; teeth number from 10 to 60;
5.   Pilot Bore T10-31 for 16mm timing belt; teeth number from 12 to 60;
6.   Pilot Bore T10-40 for 25mm timing belt; teeth number from 12 to 60;
7.   Pilot Bore T10-47 for 32mm timing belt; teeth number from 18 to 60;
8.   Pilot Bore T10-66 for 50mm timing belt; teeth number from 18 to 60;
9.  Pilot Bore AT5-21 for 10mm timing belt; teeth number from 12 to 60;
10. Pilot Bore AT5-27 for 16mm timing belt; teeth number from 12 to 60;
11. Pilot Bore AT5-36 for 25mm timing belt; teeth number from 12 to 60;
12. Pilot Bore AT10-31 for 16mm timing belt; teeth number from 15 to 60;
13. Pilot Bore AT10-40 for 25mm timing belt; teeth number from 15 to 60;
14. Pilot Bore AT10-47 for 32mm timing belt; teeth number from 18 to 60;
15. Pilot Bore AT10-66 for 50mm timing belt; teeth number from 18 to 60;

Metric Timing Belt Pulley HTD3M, 5M, 8M, 14M
1.  HTD3M-06; 3M-09; 3M-15; teeth number from 10 to 72;
2.  HTD5M-09; 5M-15; 5M-25; teeth number from 12 to 72;
3.  HTD8M-20; 8M-30; 8M-50; 8M-85 teeth number from 22 to 192;
4.  HTD14M-40; 14M-55; 14M-85; 14M-115; 14M-170; teeth number from 28-216;
5.  Taper Bore HTD5M-15; 8M-20; 8M-30; 8M-50; 8M-85; 14M-40; 14M-55; 14M-85;
     14M-115; 14M-170

Metric Timing Belt Pulleys for Poly Chain GT2 Belts
1.      PCGT8M-12; PCGT8M-21; PCGT8M-36; PCGT8M-62;
2.      PCGT14M-20; PCGT14M-37; PCGT14M-68; PCGT14M-90; PCGT14M-125;

Power Grip Gates Tooth/ PGGT 2GT, 3GT and 5GT
1. 2GT-06, 2GT-09 for timing belt width 6mm and 9mm
2. 3GT-09, 3GT-15 for timing belt width 9mm and 15mm
3. 5GT-15, 5GT-25 for timing belt width 15mm and 25mm

OMEGA RPP HTD Timing Pulleys
1.   RPP3M-06; 3M-09; 3M-15; teeth number from 10 to 72;
2.   RPP5M-09; 5M-15; 5M-25; teeth number from 12 to 72;
3.   RPP8M-20; 8M-30; 8M-50; 8M-85 teeth number from 22 to 192;
4.   RPP14M-40; 14M-55; 14M-85; 14M-115; 14M-170; teeth number from 28-216;
5.  Taper Bore RPP5M-15; 8M-20; 8M-30; 8M-50; 8M-85; 14M-40; 14M-55; 14M-85;
     14M-115; 14M-170
