High Efficiency Hypoid Gearbox Helical Gear Box Speed Reducer Hypoid Helical Gear Reducer
Zhengzhou Aokman Machinery Co., Ltd.- Application：Motor, Machinery
- Function：Speed Changing, Speed Reduction
- Layout：Orthogonal
- Hardness：Hardened Tooth Surface
- Installation：Industry
- Step：Double or Three-Step
Base Info
- Model NO.：KM
- Type：Hypoid Gearbox
- Rated Power：0.12kw-5.5kw
- Input Speed：1400r,Min
- Output Speed：4.7-187.0r,Min
- Ratio：7.48-296.10
- Output Torque：5.9-874n.M
- Accessory：Torque Arm
- Gear Housing：Cast Iron, Aluminum Alloys
- Gearing Arrangement：Hypoid
- Color：Customer′s Quest
- Gear Material：20crmnti Steel
- Housing Material：Aluminium Alloy,Cast Iron
- Mount Position：Foot Mounted. Flange Mounted
- Input Form：Mounting Motor
- Service Power Range：Service Power Range
- Warranty：1 Year
- Transport Package：Wooden Case
- Specification：ISO
- Trademark：Aokman Drive
- Origin：China
- HS Code：8483409000
- Production Capacity：3000PCS,Year
Description
Overview
Product Description3 Stage 50~300 4.8~27 130N.m Φ11 Φ20, Φ24 Φ25 2 Stage 7.5~60 24~181 130N.m Φ11 KM063 3 Stage 50~300 4.6~27 200N.m Φ11 Φ25, Φ28 Φ25 2 Stage 7.5~60 23~184 200N.m Φ14 KM075 3 Stage 50~300 4.7~28 350N.m Φ14 Φ28, Φ30, Φ35 Φ28 2 Stage 7.5~60 24~187 350N.m Φ16 KM090 3 Stage 50~300 4.7~28 500N.m Φ14 Φ35, Φ38 Φ35 2 Stage 7.5~60 24~187 500N.m Φ19 KM110 3 Stage 50~300 4.7~27 750N.m Φ19 Φ40, Φ42 Φ42 2 Stage 7.5~60 24~187 750N.m Φ24
P series planetary gearbox and R, S, K, and F series helical-tooth reducer, more
than one hundred models and thousands of specifications
2.Q:Can you make as per custom drawing?
A: Yes, we offer customized service for customers.
3.Q:What is your terms of payment ?
A: 30% Advance payment by T/T after signing the contract.70% before delivery
4.Q:What is your MOQ?
A: 1 Set
If you have any demand for our products please feel free to contact me.
Detailed Photos
2. KM series Helical-hypoid Gearbox's Main Materials
(1) Housing: die-cast aluminum alloy (frame size 27 to 57)
(2) Gear wheel: 20CrMnTiH1 carbonizing & quenching heat treatment make the hardness of gears surface be up to 56-62 HRC, and be retained carburization layers thickness between 0.3 and 0.5mm after precise grinding.
3. KM series Helical-hypoid Gearbox's Surface Painting
Aluminum alloy housing:
(1) Shot blasting and special antiseptic treatment on the aluminum alloy surface.
(2) After phosphating, spray the RAL9022 silver white paint.4.Gearbox Parameters
KM050
1.Q:What kinds of gearbox can you produce for us?
A:Main products of our company: UDL series speed variator,RV series worm gear reducer, ATA series shaft mounted gearbox, X,B series gear reducer,P series planetary gearbox and R, S, K, and F series helical-tooth reducer, more
than one hundred models and thousands of specifications
2.Q:Can you make as per custom drawing?
A: Yes, we offer customized service for customers.
3.Q:What is your terms of payment ?
A: 30% Advance payment by T/T after signing the contract.70% before delivery
4.Q:What is your MOQ?
A: 1 Set
If you have any demand for our products please feel free to contact me.
