ATA30~ATA125 Series Electric Motor Shaft Mounted Speed Reducer Gearbox
Zhengzhou Aokman Machinery Co., Ltd.- Application：Machinery, Industry
- Function：Change Drive Torque, Speed Changing, Speed Reduction
- Layout：Parallel
- Hardness：Hardened
- Installation：Torque Arm Type
- Step：Helical
Base Info
- Model NO.：ATA
- Type：Circular Gear
- Mounting Type：Tie Rod Hanging Shaft Mounted
- Input Speed：1400r,Min, 900r,Min, 500r,Min
- Ratio：I=1,5, 1,7, 1,10, 1,15, ..., 1,31.5
- Permitted Torque：180-17000n.M
- Material：Cast Iron
- Manufacturing Method：Forging, Grinding
- Toothed Portion Shape：Helical
- Rated Power：1.1kw~193kw
- Rated Torque：180~17000n.M
- Gear Profile：Hardened Helical Gears
- Output Speed：25~300r,Min
- Installation Form：Hanging Shaft Mounted
- Backstop：Optional
- Gears Accuracy：6 Class
- Shafts Material：40cr
- Transport Package：Wooden Case
- Specification：ISO
- Trademark：AOKMAN DRIVE
- Origin：China
- HS Code：8483409000
- Production Capacity：100000PCS,Year
Description
Detailed Photos
The features of ATA shaft mounted gearbox:
Mounting Type: Tie rod Hanging shaft mounted
Output Shaft: Single key hollow shaft, each model can select three hollow diameter at most.
Gearbox Housing: Hard Iron Steel, can be used outside.
Anti-slip device: Can suit for any model, It's very convenient to be mounted.
The maintenance of ATA shaft mounted gearbox:
1. Before starting the reducer must be filled of N159 or N220 extreme pressure industrial gear oils, till the gearbox oil shows an intermediate position
2. After three months running, the gearbox need to change oil, attention it must be debris inside the machine rinse before adding new oil.
3. At the reducer hollow shaft ends and drive pulley end gland plate must fastened with locking screws.
4. The reducer pulley and the motor pulley must be parallel when they are installed and the belt tightness should be moderate.
7
10
12.5
15
20
25
31
FAQ:
1.Q:What kinds of gearbox can you produce for us?
A:Main products of our company: UDL series speed variator,RV series worm gear reducer, ATA series shaft mounted gearbox, X,B series gear reducer,
P series planetary gearbox and R, S, K, and F series helical-tooth reducer, more
than one hundred models and thousands of specifications
2.Q:Can you make as per custom drawing?
A: Yes, we offer customized service for customers.
3.Q:What is your terms of payment ?
A: 30% Advance payment by T/T after signing the contract.70% before delivery
4.Q:What is your MOQ?
A: 1 Set
