Sg Series Single Screw Gear Box with Import Bearings

Hangzhou Xiaoshan Shuguang Machinery Factory
  • Application：Reducer
  • Hardness：Hardened
  • Type：Bevel Gear
  • Color：Red
  • Characteristic：Multilateral Edge
  • Material：Cast Iron

Base Info

  • Model NO.：SG250
  • Manufacturing Method：Cast Gear
  • Toothed Portion Shape：Bevel Wheel
  • Transport Package：Wooden Case
  • Specification：SGS
  • Trademark：SG
  • Origin：Original Place of China
  • HS Code：8483409000
  • Production Capacity：20000,Year

Description

Model number Thrust spherical roller bearings maximum power The screw diameter Input shaft diameter Commonly used ratio
SG10 29415 7.5KW 30-40 28 8:1  10:1  14:1  16:1
SG25 29417 11KW 40-50 32 8:1  10:1  14:1  16:1
SG35 29422 18.5KW 50-65 40 8:1  10:1  14:1  16:1  20:1
SG50 29424 30KW 55-70 45 10:1  14:1  16:1  20:1
SG65 29428 45KW 65-80 55 10:1  14:1  16:1  20:1
SG90 29432 55KW 75-90 60 10:1  14:1  16:1  20:1
SG120 29434 75KW 80-110 65 10:1  14:1  16:1  20:1
SG150 29436 85KW 90-120 75 10:1  14:1  16:1  20:1
SG180 29438 110KW 100-130 85 14:1  16:1  20:1
SG210 29440 132KW 100-130 85 14:1  16:1  20:1
SG250 29448 185KW 110-140 85 16:1  20:1
SG280 29452 200KW 120-150 95 16:1  20:1
