• Model NO.：S3M-174-8mm
• Transport Package：Carton Box
• Specification：XL L H 5M 8M 3M
• Trademark：CNFULO
• Origin：China
• HS Code：4010350000
• Production Capacity：50000 PCS , Month

TYPESUPPLY CHARACTERISTICMXL XXL XL L H XH XXH
T2.5 T5 T10 T20 AT5 AT10 AT20
HTD:2M 3M 5M 8M 14M 20M
STS:S2M S3M S4.5M S5M S8M S14M
RPP:RP2M RP3M RP5M RP8M RP14M1.Company leading products, more than 4000 moulds are available.
2.Cutting or provide sleeve according to customer's requirement.
3.Anti-static,heat-resistant,low temperature resistance ect.
4. Normal product no minimum order quantity requirements.
Tooth Profile & SizeTypePitch Pb(mm)Tooth height ht(mm)Belt thickness hs(mm)Angle β°DetailsMXL2.0320.511.1440DetailsXXL3.1750.761.5250DetailsXL5.0801.272.3050DetailsL9.5251.913.6040DetailsH12.702.294.3040DetailsXH22.2256.3511.2040DetailsXXH31.7509.5315.7040DetailsT2.52.50.71.3040DetailsT551.202.2040DetailsT10102.504.5040DetailsT20205.008.0040DetailsAT551.202.7050DetailsAT10102.505.0050DetailsAT20205.009.0050DetailsTypePitch Pb(mm)Tooth height ht(mm)Belt thickness hs(mm)Angle β°DetailsHTD2M20.751.36Details3M31.172.4Details5M52.063.8Details8M83.366.00Details14M146.0210.00Details20M208.413.20DetailsSTPD/STSS2M20.761.36DetailsS3M31.142.20DetailsS4.5M4.51.712.81DetailsS5M51.913.4DetailsS8M83.055.3DetailsS14M145.310.2DetailsRPP/HPPD2M20.761.36Details3M31.151.9Details5M51.953.5Details8M83.25.5Details14M146.0010Details





Contact information :
Acle Luo
Mobil:0086 13566060705
Company Name: Ningbo fulong synchronous belt co., ltd
Add: Longshan Town CIci City Ningbo Zhejiang China(Mainland)
