ATA Series Shaft Mounted Gearbox Reducer with Keyed Hollow Shaft Output
Zhengzhou Aokman Machinery Co., Ltd.- Application：Machinery, Industry
- Function：Change Drive Torque, Speed Changing, Speed Reduction
- Layout：Parallel
- Hardness：Hardened Tooth Surface
- Installation：Horizontal Type
- Step：Single-Step
Base Info
- Model NO.：shaft mounted gearbox
- Type：Circular Gear
- Model：ATA70d
- Manufacturing Method：Forging, Grinding
- Toothed Portion Shape：Helical
- Rated Power：1.1kw-193kw
- Speed Ratio：5-31
- Rated Torque：180-17000n.M
- Voltage：380-440V
- Colour：Gray, Blue or as Your Request
- Gears Profile：Hardened Helical Gears
- Gears Material：20crmnti 4
- Gears Processing：Carburizing, Quenching, Grinding
- Gears Hardness：HRC58-62
- Gears Accuracy：6 Class
- Shafts Material：40cr
- Input Configurations：Keyed Solid Shaft Input IEC Normalized Motor Flang
- Transport Package：Plywood Case
- Specification：ISO
- Trademark：AOKMAN DRIVE
- Origin：China
- HS Code：8483409000
- Production Capacity：5000PCS,Year
Description
5
7
10
12.5
15
20
25
31ATA35 35mm 420Nm ATA40 40mm/45mm 950Nm ATA45 45mm/50mm/55mm 1400Nm ATA50 50mm/55mm/60mm 2300Nm ATA60 60mm/70mm 3600Nm ATA70 70mm/85mm 5100Nm ATA80 80mm/100mm 7000Nm ATA100 100mm/125mm 11000Nm ATA125 125mm/135mm 17000Nm
Services during selling1.Pre-check and accept products ahead of delivery. 2. Help clients to draft solving plans. After-sale services 1.Assist clients to prepare for the first construction scheme. 2. Train the first-line operators. 3.Take initiative to eliminate the trouble rapidly. 4. Provide technical exchanging.
FAQ:
1.Q:What kinds of gearbox can you produce for us?
A:Main products of our company: UDL series speed variator,RV series worm gear reducer, ATA series shaft mounted gearbox, X,B series gear reducer,
P series planetary gearbox and R, S, K, and F series helical-tooth reducer, more
than one hundred models and thousands of specifications
2.Q:Can you make as per custom drawing?
A: Yes, we offer customized service for customers.
3.Q:What is your terms of payment ?
A: 30% Advance payment by T/T after signing the contract.70% before delivery
4.Q:What is your MOQ?
A: 1 Set
If you have any demand for our products please feel free to contact me
